Daikin SUPER MULTI NX G Series User Manual

EDUS121131 Specifications
SUPER MULTI NX 2/3/4MXS-G/J Series Heat Pump 47
1
09+09+18 Duct Duct Wall — 7.05 7.05 16.90 — 31.00 12.10 ~ 33.40 2920 1000 ~ 3470 13.0 4.4 ~ 15.4 98
09+09+18 Duct Duct Duct — 6.91 6.91 16.58 — 30.40 12.20 ~ 32.80 3170 1190 ~ 3740 14.1 5.3 ~ 16.6 98
09+12+12 Wall Wall Wall — 8.28 11.61 11.61 — 31.50 9.90 ~ 33.70 2970 800 ~ 3460 13.2 3.5 ~ 15.4 98
09+12+12 Wall Wall Duct — 8.16 11.42 11.42 — 31.00 9.90 ~ 33.40 3060 870 ~ 3630 13.6 3.9 ~ 16.1 98
09+12+12 Wall Duct Duct — 8.02 11.24 11.24 — 30.50 10.00 ~ 32.50 3170 950 ~ 3630 14.1 4.2 ~ 16.1 98
09+12+12 Duct Wall Wall — 8.16 11.42 11.42 — 31.00 9.90 ~ 33.40 3060 870 ~ 3630 13.6 3.9 ~ 16.1 98
09+12+12 Duct Wall Duct — 8.02 11.24 11.24 — 30.50 10.00 ~ 32.50 3170 950 ~ 3630 14.1 4.2 ~ 16.1 98
09+12+12 Duct Duct Duct — 7.90 11.05 11.05 — 30.00 10.10 ~ 31.50 3300 1030 ~ 3650 14.6 4.6 ~ 16.2 98
09+12+15 Wall Wall Wall — 7.30 10.21 14.59 — 32.10 12.00 ~ 34.20 2870 880 ~ 3290 12.7 3.9 ~ 14.6 98
09+12+15 Wall Wall Duct — 7.16 10.02 14.32 — 31.50 12.10 ~ 33.90 3040 1040 ~ 3530 13.5 4.6 ~ 15.7 98
09+12+15 Wall Duct Wall — 7.16 10.02 14.32 — 31.50 12.10 ~ 33.90 2930 940 ~ 3420 13.0 4.2 ~ 15.2 98
09+12+15 Wall Duct Duct — 7.05 9.86 14.09 — 31.00 12.10 ~ 33.40 3130 1110 ~ 3630 13.9 4.9 ~ 16.1 98
09+12+15 Duct Wall Wall — 7.16 10.02 14.32 — 31.50 12.10 ~ 33.90 2930 940 ~ 3420 13.0 4.2 ~ 15.2 98
09+12+15 Duct Wall Duct — 7.05 9.86 14.09 — 31.00 12.10 ~ 33.40 3130 1110 ~ 3630 13.9 4.9 ~ 16.1 98
09+12+15 Duct Duct Wall — 7.05 9.86 14.09 — 31.00 12.10 ~ 33.40 2960 1020 ~ 3500 13.1 4.5 ~ 15.5 98
09+12+15 Duct Duct Duct — 6.91 9.67 13.82 — 30.40 12.20 ~ 32.80 3170 1190 ~ 3740 14.1 5.3 ~ 16.6 98
09+12+18 Wall Wall Wall — 6.79 9.51 16.30 — 32.60 12.00 ~ 34.20 2950 870 ~ 3270 13.1 3.9 ~ 14.5 98
09+12+18 Wall Wall Duct — 6.67 9.33 16.00 — 32.00 12.10 ~ 33.90 3150 1040 ~ 3530 14.0 4.6 ~ 15.7 98
09+12+18 Wall Duct Wall — 6.67 9.33 16.00 — 32.00 12.00 ~ 33.90 2950 930 ~ 3380 13.1 4.1 ~ 15.0 98
09+12+18 Wall Duct Duct — 6.56 9.19 15.75 — 31.50 12.10 ~ 33.40 3180 1110 ~ 3630 14.1 4.9 ~ 16.1 98
09+12+18 Duct Wall Wall — 6.67 9.33 16.00 — 32.00 12.00 ~ 33.90 2950 930 ~ 3380 13.1 4.1 ~ 15.0 98
09+12+18 Duct Wall Duct — 6.56 9.19 15.75 — 31.50 12.10 ~ 33.40 3180 1110 ~ 3630 14.1 4.9 ~ 16.1 98
09+12+18 Duct Duct Wall — 6.56 9.19 15.75 — 31.50 12.10 ~ 33.40 3030 1000 ~ 3470 13.4 4.4 ~ 15.4 98
09+12+18 Duct Duct Duct — 6.44 9.01 15.45 — 30.90 12.20 ~ 32.80 3280 1190 ~ 3740 14.6 5.3 ~ 16.6 98
09+15+15 Wall Wall Wall — 6.52 13.04 13.04 — 32.60 11.90 ~ 34.50 2830 850 ~ 3190 12.6 3.8 ~ 14.2 98
09+15+15 Wall Wall Duct — 6.40 12.80 12.80 — 32.00 12.00 ~ 33.90 2960 990 ~ 3330 13.1 4.4 ~ 14.8 98
09+15+15 Wall Duct Duct — 6.30 12.60 12.60 — 31.50 12.00 ~ 33.40 3070 1150 ~ 3500 13.6 5.1 ~ 15.5 98
09+15+15 Duct Wall Wall — 6.40 12.80 12.80 — 32.00 11.90 ~ 33.90 2810 900 ~ 3230 12.5 4.0 ~ 14.3 98
09+15+15 Duct Wall Duct — 6.30 12.60 12.60 — 31.50 12.00 ~ 33.40 2960 1060 ~ 3390 13.1 4.7 ~ 15.0 98
09+15+15 Duct Duct Duct — 6.18 12.36 12.36 — 30.90 12.10 ~ 32.80 3150 1220 ~ 3520 14.0 5.4 ~ 15.6 98
09+15+18 Wall Wall Wall — 6.13 12.26 14.71 — 33.10 11.90 ~ 34.50 2920 850 ~ 3180 13.0 3.8 ~ 14.1 98
09+15+18 Wall Wall Duct — 6.02 12.04 14.44 — 32.50 12.00 ~ 34.00 3010 990 ~ 3330 13.4 4.4 ~ 14.8 98
09+15+18 Wall Duct Wall — 6.02 12.04 14.44 — 32.50 11.90 ~ 34.00 2990 990 ~ 3310 13.3 4.4 ~ 14.7 98
09+15+18 Wall Duct Duct — 5.93 11.85 14.22 — 32.00 12.00 ~ 33.50 3180 1150 ~ 3500 14.1 5.1 ~ 15.5 98
09+15+18 Duct Wall Wall — 6.02 12.04 14.44 — 32.50 11.90 ~ 34.00 2890 900 ~ 3210 12.8 4.0 ~ 14.2 98
09+15+18 Duct Wall Duct — 5.93 11.85 14.22 — 32.00 12.00 ~ 33.50 3070 1060 ~ 3390 13.6 4.7 ~ 15.0 98
09+15+18 Duct Duct Wall — 5.93 11.85 14.22 — 32.00 12.00 ~ 33.50 3040 1050 ~ 3360 13.5 4.7 ~ 14.9 98
09+15+18 Duct Duct Duct — 5.81 11.63 13.96 — 31.40 12.10 ~ 32.90 3250 1220 ~ 3580 14.4 5.4 ~ 15.9 98
09+18+18 Wall Wall Wall — 5.80 13.90 13.90 — 33.60 11.80 ~ 34.50 3020 840 ~ 3180 13.4 3.7 ~ 14.1 98
09+18+18 Wall Wall Duct — 5.68 13.66 13.66 — 33.00 11.90 ~ 34.00 3100 990 ~ 3310 13.8 4.4 ~ 14.7 98
09+18+18 Wall Duct Duct — 5.60 13.45 13.45 — 32.50 12.00 ~ 33.50 3280 1150 ~ 3500 14.6 5.1 ~ 15.5 98
09+18+18 Duct Wall Wall — 5.68 13.66 13.66 — 33.00 11.90 ~ 34.00 2980 900 ~ 3190 13.2 4.0 ~ 14.2 98
09+18+18 Duct Wall Duct — 5.60 13.45 13.45 — 32.50 12.00 ~ 33.50 3150 1050 ~ 3360 14.0 4.7 ~ 14.9 98
09+18+18 Duct Duct Duct — 5.50 13.20 13.20 — 31.90 12.10 ~ 32.90 3310 1220 ~ 3580 14.7 5.4 ~ 15.9 98
12+12+12 Wall Wall Wall — 10.70 10.70 10.70 — 32.10 9.90 ~ 33.70 3080 800 ~ 3460 13.7 3.5 ~ 15.4 98
12+12+12 Wall Wall Duct — 10.50 10.50 10.50 — 31.50 9.90 ~ 33.40 3170 870 ~ 3630 14.1 3.9 ~ 16.1 98
12+12+12 Wall Duct Duct — 10.33 10.33 10.33 — 31.00 10.00 ~ 32.50 3280 950 ~ 3630 14.6 4.2 ~ 16.1 98
12+12+12 Duct Duct Duct — 10.13 10.13 10.13 — 30.40 10.10 ~ 31.50 3410 1030 ~ 3650 15.1 4.6 ~ 16.2 98
12+12+15 Wall Wall Wall — 9.51 9.51 13.58 — 32.60 12.00 ~ 34.20 2970 880 ~ 3290 13.2 3.9 ~ 14.6 98
12+12+15 Wall Wall Duct — 9.33 9.33 13.34 — 32.00 12.10 ~ 33.90 3150 1040 ~ 3530 14.0 4.6 ~ 15.7 98
12+12+15 Wall Duct Wall — 9.33 9.33 13.34 — 32.00 12.10 ~ 33.90 2980 940 ~ 3420 13.2 4.2 ~ 15.2 98
12+12+15 Wall Duct Duct — 9.19 9.19 13.12 — 31.50 12.10 ~ 33.40 3180 1110 ~ 3630 14.1 4.9 ~ 16.1 98
12+12+15 Duct Duct Wall — 9.19 9.19 13.12 — 31.50 12.10 ~ 33.40 3060 1020 ~ 3500 13.6 4.5 ~ 15.5 98
12+12+15 Duct Duct Duct — 9.01 9.01 12.88 — 30.90 12.20 ~ 32.80 3280 1190 ~ 3740 14.6 5.3 ~ 16.6 98
12+12+18 Wall Wall Wall — 8.91 8.91 15.28 — 33.10 12.00 ~ 34.20 3050 870 ~ 3270 13.5 3.9 ~ 14.5 98
12+12+18 Wall Wall Duct — 8.75 8.75 15.00 — 32.50 12.10 ~ 33.90 3200 1040 ~ 3530 14.2 4.6 ~ 15.7 98
12+12+18 Wall Duct Wall — 8.75 8.75 15.00 — 32.50 12.00 ~ 34.00 3060 930 ~ 3380 13.6 4.1 ~ 15.0 98
12+12+18 Wall Duct Duct — 8.62 8.62 14.76 — 32.00 12.10 ~ 33.50 3290 1110 ~ 3680 14.6 4.9 ~ 16.3 98
12+12+18 Duct Duct Wall — 8.62 8.62 14.76 — 32.00 12.10 ~ 33.50 3140 1000 ~ 3470 13.9 4.4 ~ 15.4 98
12+12+18 Duct Duct Duct — 8.45 8.45 14.50 — 31.40 12.20 ~ 32.90 3390 1190 ~ 3740 15.0 5.3 ~ 16.6 98
12+15+15 Wall Wall Wall — 8.58 12.26 12.26 — 33.10 11.90 ~ 34.50 2930 850 ~ 3190 13.0 3.8 ~ 14.2 98
Combination
of
indoor unit
Type of indoor unit
Capacity of each indoor unit
Each capacity (kBtu/h) Total capacity (kBtu/h) Total input (W) Total current (A)
Power
factor (%)
A room B room C room D room A room B room C room D room Rating ( min ~ max ) Rating ( min ~ max ) Rating ( min ~ max ) Rating
