Daikin SUPER MULTI NX G Series User Manual

Specifications EDUS121131
50 SUPER MULTI NX 2/3/4MXS-G/J Series Heat Pump
09+09+12+12 Wall Duct Duct Duct 6.63 6.63 9.27 9.27 31.80 12.00 ~ 33.30 2980 1020 ~ 3300 13.2 4.5 ~ 14.6 98
09+09+12+12 Duct Duct Wall Wall 6.73 6.73 9.42 9.42 32.30 12.00 ~ 33.80 2980 960 ~ 3240 13.2 4.3 ~ 14.4 98
09+09+12+12 Duct Duct Wall Duct 6.63 6.63 9.27 9.27 31.80 12.00 ~ 33.30 2980 1020 ~ 3300 13.2 4.5 ~ 14.6 98
09+09+12+12 Duct Duct Duct Duct 6.54 6.54 9.16 9.16 31.40 12.10 ~ 32.90 3050 1090 ~ 3380 13.5 4.8 ~ 15.0 98
09+09+12+15 Wall Wall Wall Wall 6.22 6.22 8.72 12.44 33.60 11.70 ~ 34.60 3020 840 ~ 3180 13.4 3.7 ~ 14.1 98
09+09+12+15 Wall Wall Wall Duct 6.15 6.15 8.60 12.30 33.20 11.80 ~ 34.20 3040 970 ~ 3250 13.5 4.3 ~ 14.4 98
09+09+12+15 Wall Wall Duct Wall 6.15 6.15 8.60 12.30 33.20 11.80 ~ 34.20 2950 890 ~ 3160 13.1 3.9 ~ 14.0 98
09+09+12+15 Wall Wall Duct Duct 6.07 6.07 8.51 12.15 32.80 11.90 ~ 33.80 3050 1020 ~ 3260 13.5 4.5 ~ 14.5 98
09+09+12+15 Wall Duct Wall Wall 6.15 6.15 8.60 12.30 33.20 11.80 ~ 34.20 2950 890 ~ 3160 13.1 3.9 ~ 14.0 98
09+09+12+15 Wall Duct Wall Duct 6.07 6.07 8.51 12.15 32.80 11.90 ~ 33.80 3050 1020 ~ 3260 13.5 4.5 ~ 14.5 98
09+09+12+15 Wall Duct Duct Wall 6.07 6.07 8.51 12.15 32.80 11.90 ~ 33.80 2960 930 ~ 3110 13.1 4.1 ~ 13.8 98
09+09+12+15 Wall Duct Duct Duct 5.98 5.98 8.38 11.96 32.30 11.90 ~ 33.30 3030 1080 ~ 3230 13.4 4.8 ~ 14.3 98
09+09+12+15 Duct Duct Wall Wall 6.07 6.07 8.51 12.15 32.80 11.90 ~ 33.80 2960 930 ~ 3110 13.1 4.1 ~ 13.8 98
09+09+12+15 Duct Duct Wall Duct 5.98 5.98 8.38 11.96 32.30 11.90 ~ 33.30 3030 1080 ~ 3230 13.4 4.8 ~ 14.3 98
09+09+12+15 Duct Duct Duct Wall 5.98 5.98 8.38 11.96 32.30 11.90 ~ 33.30 2930 990 ~ 3130 13.0 4.4 ~ 13.9 98
09+09+12+15 Duct Duct Duct Duct 5.91 5.91 8.27 11.81 31.90 12.00 ~ 32.90 3070 1140 ~ 3280 13.6 5.1 ~ 14.6 98
09+12+12+12 Wall Wall Wall Wall 6.45 9.05 9.05 9.05 33.60 11.90 ~ 34.50 3020 840 ~ 3180 13.4 3.7 ~ 14.1 98
09+12+12+12 Wall Wall Wall Duct 6.38 8.94 8.94 8.94 33.20 11.90 ~ 34.20 3040 900 ~ 3200 13.5 4.0 ~ 14.2 98
09+12+12+12 Wall Wall Duct Duct 6.31 8.83 8.83 8.83 32.80 12.00 ~ 33.80 3030 960 ~ 3240 13.4 4.3 ~ 14.4 98
09+12+12+12 Wall Duct Duct Duct 6.20 8.70 8.70 8.70 32.30 12.00 ~ 33.30 3090 1020 ~ 3300 13.7 4.5 ~ 14.6 98
09+12+12+12 Duct Wall Wall Wall 6.38 8.94 8.94 8.94 33.20 11.90 ~ 34.20 3040 900 ~ 3200 13.5 4.0 ~ 14.2 98
09+12+12+12 Duct Wall Wall Duct 6.31 8.83 8.83 8.83 32.80 12.00 ~ 33.80 3030 960 ~ 3240 13.4 4.3 ~ 14.4 98
09+12+12+12 Duct Wall Duct Duct 6.20 8.70 8.70 8.70 32.30 12.00 ~ 33.30 3090 1020 ~ 3300 13.7 4.5 ~ 14.6 98
09+12+12+12 Duct Duct Duct Duct 6.13 8.59 8.59 8.59 31.90 12.10 ~ 32.90 3160 1090 ~ 3380 14.0 4.8 ~ 15.0 98
Combination
of
indoor unit
Type of indoor unit
Capacity of each indoor unit
Each capacity (kBtu/h) Total capacity (kBtu/h) Total input (W) Total current (A)
Power
factor (%)
A room B room C room D room A room B room C room D room Rating ( min ~ max ) Rating ( min ~ max ) Rating ( min ~ max ) Rating
Note:
1. Cooling capacity is based on 80°FDB (26.7°CDB) / 67°FWB (19.4°CWB) (Indoor temperature), 95°FDB
(35°CDB) / 75°FWB (24°CWB) (Outdoor temperature).
Heating capacity is based on 70°FDB (21°CDB) / 60°FWB (15.6°CWB) (Indoor temperature), 47°FDB
(8.3°CDB) / 43°FWB (6°CWB) (Outdoor temperature).
2. The total ability of connected indoor units is up to 45.0 kBtu/h.
3. It is impossible to connect only one indoor unit.
4. Wall type of indoor unit: CTXS-L, FTXS-L series
Duct type of indoor unit: CDXS-L, FDXS-L series
3D078872
3D078873
3D078874
3D078875
3D078876
3D078877
3D078878
3D078879
