Daikin SUPER MULTI NX G Series User Manual

Specifications EDUS121131
16 SUPER MULTI NX 2/3/4MXS-G/J Series Heat Pump
07+07+12 Wall Wall Wall — 6.40 6.40 11.20 — 24.00 10.70 ~ 24.40 1910 700 ~ 1970 9.4 3.4 ~ 9.7 98
07+07+12 Wall Wall Duct — 6.40 6.40 11.20 — 24.00 10.40 ~ 24.00 2100 750 ~ 2100 10.3 3.7 ~ 10.3 98
07+07+15 Wall Wall Wall — 5.33 5.33 13.34 — 24.00 14.50 ~ 25.50 1820 910 ~ 2030 8.9 4.5 ~ 10.0 98
07+07+15 Wall Wall Duct — 5.33 5.33 13.34 — 24.00 14.20 ~ 24.40 2000 1040 ~ 2050 9.8 5.1 ~ 10.1 98
07+07+18 Wall Wall Wall — 4.80 4.80 14.40 — 24.00 14.60 ~ 26.20 1830 910 ~ 2140 9.0 4.5 ~ 10.5 98
07+07+18 Wall Wall Duct — 4.80 4.80 14.40 — 24.00 14.20 ~ 25.10 2000 1040 ~ 2160 9.8 5.1 ~ 10.6 98
07+09+09 Wall Wall Wall — 6.86 8.57 8.57 — 24.00 10.10 ~ 24.00 1910 670 ~ 1910 9.4 3.3 ~ 9.4 98
07+09+09 Wall Wall Duct — 6.78 8.46 8.46 — 23.70 9.80 ~ 23.70 2050 720 ~ 2050 10.1 3.5 ~ 10.1 98
07+09+09 Wall Duct Duct — 6.68 8.36 8.36 — 23.40 9.50 ~ 23.40 2180 770 ~ 2180 10.7 3.8 ~ 10.7 98
07+09+12 Wall Wall Wall — 6.00 7.50 10.50 — 24.00 10.70 ~ 24.70 1910 700 ~ 2020 9.4 3.4 ~ 9.9 98
07+09+12 Wall Wall Duct — 6.00 7.50 10.50 — 24.00 10.40 ~ 24.30 2100 750 ~ 2150 10.3 3.7 ~ 10.5 98
07+09+12 Wall Duct Wall — 6.00 7.50 10.50 — 24.00 10.40 ~ 24.30 2100 750 ~ 2150 10.3 3.7 ~ 10.5 98
07+09+12 Wall Duct Duct — 6.00 7.50 10.50 — 24.00 10.00 ~ 24.00 2280 800 ~ 2280 11.2 3.9 ~ 11.2 98
07+09+15 Wall Wall Wall — 5.05 6.32 12.63 — 24.00 14.50 ~ 25.80 1820 910 ~ 2090 8.9 4.5 ~ 10.3 98
07+09+15 Wall Wall Duct — 5.05 6.32 12.63 — 24.00 14.20 ~ 24.80 2000 1040 ~ 2100 9.8 5.1 ~ 10.3 98
07+09+15 Wall Duct Wall — 5.05 6.32 12.63 — 24.00 14.10 ~ 25.40 1960 950 ~ 2170 9.6 4.7 ~ 10.6 98
07+09+15 Wall Duct Duct — 5.05 6.32 12.63 — 24.00 13.80 ~ 24.40 2180 1080 ~ 2240 10.7 5.3 ~ 11.0 98
07+09+18 Wall Wall Wall — 4.57 5.71 13.72 — 24.00 14.60 ~ 26.50 1830 910 ~ 2200 9.0 4.5 ~ 10.8 98
07+09+18 Wall Wall Duct — 4.57 5.71 13.72 — 24.00 14.20 ~ 25.30 2000 1040 ~ 2210 9.8 5.1 ~ 10.8 98
07+09+18 Wall Duct Wall — 4.57 5.71 13.72 — 24.00 14.10 ~ 26.10 1960 950 ~ 2280 9.6 4.7 ~ 11.2 98
07+09+18 Wall Duct Duct — 4.57 5.71 13.72 — 24.00 13.80 ~ 24.90 2180 1080 ~ 2290 10.7 5.3 ~ 11.2 98
07+12+12 Wall Wall Wall — 5.34 9.33 9.33 — 24.00 14.00 ~ 25.50 1910 910 ~ 2180 9.4 4.5 ~ 10.7 98
07+12+12 Wall Wall Duct — 5.34 9.33 9.33 — 24.00 13.60 ~ 25.00 2100 950 ~ 2260 10.3 4.7 ~ 11.1 98
07+12+12 Wall Duct Duct — 5.34 9.33 9.33 — 24.00 13.00 ~ 24.50 2280 990 ~ 2400 11.2 4.9 ~ 11.8 98
07+12+15 Wall Wall Wall — 4.57 8.00 11.43 — 24.00 14.50 ~ 26.50 1820 910 ~ 2200 8.9 4.5 ~ 10.8 98
07+12+15 Wall Wall Duct — 4.57 8.00 11.43 — 24.00 14.20 ~ 25.30 2000 1040 ~ 2210 9.8 5.1 ~ 10.8 98
07+12+15 Wall Duct Wall — 4.57 8.00 11.43 — 24.00 14.10 ~ 26.10 1960 950 ~ 2340 9.6 4.7 ~ 11.5 98
07+12+15 Wall Duct Duct — 4.57 8.00 11.43 — 24.00 13.80 ~ 24.90 2180 1080 ~ 2290 10.7 5.3 ~ 11.2 98
07+12+18 Wall Wall Wall — 4.17 7.30 12.53 — 24.00 14.60 ~ 27.30 1830 910 ~ 2370 9.0 4.5 ~ 11.6 98
07+12+18 Wall Wall Duct — 4.17 7.30 12.53 — 24.00 14.20 ~ 26.80 2000 1040 ~ 2490 9.8 5.1 ~ 12.2 98
07+12+18 Wall Duct Wall — 4.17 7.30 12.53 — 24.00 14.10 ~ 26.80 1960 950 ~ 2450 9.6 4.7 ~ 12.0 98
07+12+18 Wall Duct Duct — 4.17 7.30 12.53 — 24.00 13.80 ~ 26.00 2180 1080 ~ 2510 10.7 5.3 ~ 12.3 98
07+15+15 Wall Wall Wall — 4.00 10.00 10.00 — 24.00 14.90 ~ 27.60 1730 900 ~ 2330 8.5 4.4 ~ 11.4 98
07+15+15 Wall Wall Duct — 4.00 10.00 10.00 — 24.00 14.70 ~ 27.20 1910 1030 ~ 2450 9.4 5.1 ~ 12.0 98
07+15+15 Wall Duct Duct — 4.00 10.00 10.00 — 24.00 14.40 ~ 26.80 2080 1170 ~ 2570 10.2 5.7 ~ 12.6 98
09+09+09 Wall Wall Wall — 8.00 8.00 8.00 — 24.00 10.70 ~ 24.40 1910 700 ~ 1970 9.4 3.4 ~ 9.7 98
09+09+09 Wall Wall Duct — 8.00 8.00 8.00 — 24.00 10.40 ~ 24.00 2100 750 ~ 2100 10.3 3.7 ~ 10.3 98
09+09+09 Wall Duct Duct — 7.90 7.90 7.90 — 23.70 10.00 ~ 23.70 2230 800 ~ 2230 10.9 3.9 ~ 10.9 98
09+09+09 Duct Duct Duct — 7.83 7.83 7.83 — 23.50 9.60 ~ 23.50 2410 840 ~ 2410 11.8 4.1 ~ 11.8 98
09+09+12 Wall Wall Wall — 7.06 7.06 9.88 — 24.00 10.70 ~ 25.00 1910 700 ~ 2070 9.4 3.4 ~ 10.2 98
09+09+12 Wall Wall Duct — 7.06 7.06 9.88 — 24.00 10.40 ~ 24.60 2100 750 ~ 2210 10.3 3.7 ~ 10.8 98
09+09+12 Wall Duct Wall — 7.06 7.06 9.88 — 24.00 10.40 ~ 24.60 2100 750 ~ 2210 10.3 3.7 ~ 10.8 98
09+09+12 Wall Duct Duct — 7.06 7.06 9.88 — 24.00 10.00 ~ 24.20 2280 800 ~ 2340 11.2 3.9 ~ 11.5 98
09+09+12 Duct Duct Wall — 7.06 7.06 9.88 — 24.00 10.00 ~ 24.20 2280 800 ~ 2340 11.2 3.9 ~ 11.5 98
09+09+12 Duct Duct Duct — 7.06 7.06 9.88 — 24.00 9.60 ~ 24.00 2530 840 ~ 2530 12.4 4.1 ~ 12.4 98
09+09+15 Wall Wall Wall — 6.00 6.00 12.00 — 24.00 14.50 ~ 26.20 1820 910 ~ 2140 8.9 4.5 ~ 10.5 98
09+09+15 Wall Wall Duct — 6.00 6.00 12.00 — 24.00 14.20 ~ 25.70 2000 1040 ~ 2260 9.8 5.1 ~ 11.1 98
09+09+15 Wall Duct Wall — 6.00 6.00 12.00 — 24.00 14.10 ~ 25.80 1960 950 ~ 2280 9.6 4.7 ~ 11.2 98
09+09+15 Wall Duct Duct — 6.00 6.00 12.00 — 24.00 13.80 ~ 25.40 2180 1080 ~ 2400 10.7 5.3 ~ 11.8 98
09+09+15 Duct Duct Wall — 6.00 6.00 12.00 — 24.00 13.60 ~ 25.40 2140 1000 ~ 2360 10.5 4.9 ~ 11.6 98
09+09+15 Duct Duct Duct — 6.00 6.00 12.00 — 24.00 13.30 ~ 24.80 2320 1120 ~ 2480 11.4 5.5 ~ 12.2 98
09+09+18 Wall Wall Wall — 5.45 5.45 13.10 — 24.00 14.60 ~ 26.90 1830 910 ~ 2310 9.0 4.5 ~ 11.3 98
09+09+18 Wall Wall Duct — 5.45 5.45 13.10 — 24.00 14.20 ~ 26.50 2000 1040 ~ 2430 9.8 5.1 ~ 11.9 98
09+09+18 Wall Duct Wall — 5.45 5.45 13.10 — 24.00 14.10 ~ 26.50 1960 950 ~ 2400 9.6 4.7 ~ 11.8 98
09+09+18 Wall Duct Duct — 5.45 5.45 13.10 — 24.00 13.80 ~ 25.90 2180 1080 ~ 2510 10.7 5.3 ~ 12.3 98
09+09+18 Duct Duct Wall — 5.45 5.45 13.10 — 24.00 13.60 ~ 25.90 2090 1000 ~ 2480 10.3 4.9 ~ 12.2 98
09+09+18 Duct Duct Duct — 5.45 5.45 13.10 — 24.00 13.30 ~ 25.30 2320 1120 ~ 2590 11.4 5.5 ~ 12.7 98
09+12+12 Wall Wall Wall — 6.32 8.84 8.84 — 24.00 14.00 ~ 25.80 1910 910 ~ 2240 9.4 4.5 ~ 11.0 98
09+12+12 Wall Wall Duct — 6.32 8.84 8.84 — 24.00 11.50 ~ 25.30 2100 820 ~ 2320 10.3 4.0 ~ 11.4 98
09+12+12 Wall Duct Duct — 6.32 8.84 8.84 — 24.00 11.00 ~ 24.80 2280 860 ~ 2450 11.2 4.2 ~ 12.0 98
09+12+12 Duct Wall Wall — 6.32 8.84 8.84 — 24.00 11.50 ~ 25.30 2100 820 ~ 2320 10.3 4.0 ~ 11.4 98
Combination
of
indoor unit
Type of indoor unit
Capacity of each indoor unit
Each capacity (kBtu/h) Total capacity (kBtu/h) Total input (W) Total current (A)
Power
factor (%)
A room B room C room — A room B room C room — Rating (min ~ max) Rating (min ~ max) Rating (min ~ max) Rating

Daikin SUPER MULTI NX G Series Specifications

General

Brand	Daikin
Model	SUPER MULTI NX G Series
Category	Air Conditioner
Language	English
