Daikin SUPER MULTI NX G Series User Manual

EDUS121131 Specifications
SUPER MULTI NX 2/3/4MXS-G/J Series Heat Pump 17
1
09+12+12 Duct Wall Duct — 6.32 8.84 8.84 — 24.00 11.00 ~ 24.80 2280 860 ~ 2450 11.2 4.2 ~ 12.0 98
09+12+12 Duct Duct Duct — 6.32 8.84 8.84 — 24.00 10.60 ~ 24.20 2530 900 ~ 2530 12.4 4.4 ~ 12.4 98
09+12+15 Wall Wall Wall — 5.45 7.64 10.91 — 24.00 14.50 ~ 26.90 1820 910 ~ 2310 8.9 4.5 ~ 11.3 98
09+12+15 Wall Wall Duct — 5.45 7.64 10.91 — 24.00 14.20 ~ 26.50 2000 1040 ~ 2430 9.8 5.1 ~ 11.9 98
09+12+15 Wall Duct Wall — 5.45 7.64 10.91 — 24.00 14.10 ~ 26.50 1960 950 ~ 2390 9.6 4.7 ~ 11.7 98
09+12+15 Wall Duct Duct — 5.45 7.64 10.91 — 24.00 13.80 ~ 25.80 2180 1080 ~ 2510 10.7 5.3 ~ 12.3 98
09+12+15 Duct Wall Wall — 5.45 7.64 10.91 — 24.00 14.10 ~ 26.50 1960 950 ~ 2390 9.6 4.7 ~ 11.7 98
09+12+15 Duct Wall Duct — 5.45 7.64 10.91 — 24.00 13.80 ~ 25.80 2180 1080 ~ 2510 10.7 5.3 ~ 12.3 98
09+12+15 Duct Duct Wall — 5.45 7.64 10.91 — 24.00 13.60 ~ 25.80 2140 1000 ~ 2480 10.5 4.9 ~ 12.2 98
09+12+15 Duct Duct Duct — 5.45 7.64 10.91 — 24.00 13.30 ~ 25.20 2320 1120 ~ 2590 11.4 5.5 ~ 12.7 98
09+12+18 Wall Wall Wall — 5.00 7.00 12.00 — 24.00 14.60 ~ 27.60 1830 910 ~ 2430 9.0 4.5 ~ 11.9 98
09+12+18 Wall Wall Duct — 5.00 7.00 12.00 — 24.00 14.20 ~ 27.00 2000 1040 ~ 2550 9.8 5.1 ~ 12.5 98
09+12+18 Wall Duct Wall — 5.00 7.00 12.00 — 24.00 14.10 ~ 27.00 1960 950 ~ 2510 9.6 4.7 ~ 12.3 98
09+12+18 Wall Duct Duct — 5.00 7.00 12.00 — 24.00 13.80 ~ 26.40 2180 1080 ~ 2630 10.7 5.3 ~ 12.9 98
09+12+18 Duct Wall Wall — 5.00 7.00 12.00 — 24.00 14.10 ~ 27.00 1960 950 ~ 2510 9.6 4.7 ~ 12.3 98
09+12+18 Duct Wall Duct — 5.00 7.00 12.00 — 24.00 13.80 ~ 26.40 2180 1080 ~ 2630 10.7 5.3 ~ 12.9 98
09+12+18 Duct Duct Wall — 5.00 7.00 12.00 — 24.00 13.60 ~ 26.40 2090 1000 ~ 2590 10.3 4.9 ~ 12.7 98
09+12+18 Duct Duct Duct — 5.00 7.00 12.00 — 24.00 13.30 ~ 25.90 2320 1120 ~ 2710 11.4 5.5 ~ 13.3 98
09+15+15 Wall Wall Wall — 4.80 9.60 9.60 — 24.00 14.90 ~ 28.00 1730 900 ~ 2390 8.5 4.4 ~ 11.7 98
09+15+15 Wall Wall Duct — 4.80 9.60 9.60 — 24.00 14.70 ~ 27.50 1910 1030 ~ 2510 9.4 5.1 ~ 12.3 98
09+15+15 Wall Duct Duct — 4.80 9.60 9.60 — 24.00 14.40 ~ 27.10 2080 1170 ~ 2630 10.2 5.7 ~ 12.9 98
09+15+15 Duct Wall Wall — 4.80 9.60 9.60 — 24.00 14.50 ~ 27.50 1870 950 ~ 2470 9.2 4.7 ~ 12.1 98
09+15+15 Duct Wall Duct — 4.80 9.60 9.60 — 24.00 14.30 ~ 27.10 2040 1080 ~ 2590 10.0 5.3 ~ 12.7 98
09+15+15 Duct Duct Duct — 4.80 9.60 9.60 — 24.00 14.00 ~ 26.70 2220 1210 ~ 2710 10.9 5.9 ~ 13.3 98
12+12+12 Wall Wall Wall — 8.00 8.00 8.00 — 24.00 14.00 ~ 26.50 1910 910 ~ 2350 9.4 4.5 ~ 11.5 98
12+12+12 Wall Wall Duct — 8.00 8.00 8.00 — 24.00 11.50 ~ 25.90 2100 820 ~ 2430 10.3 4.0 ~ 11.9 98
12+12+12 Wall Duct Duct — 8.00 8.00 8.00 — 24.00 11.00 ~ 25.50 2280 860 ~ 2620 11.2 4.2 ~ 12.9 98
12+12+12 Duct Duct Duct — 8.00 8.00 8.00 — 24.00 10.60 ~ 24.70 2530 900 ~ 2700 12.4 4.4 ~ 13.2 98
12+12+15 Wall Wall Wall — 7.00 7.00 10.00 — 24.00 14.50 ~ 27.60 1820 910 ~ 2430 8.9 4.5 ~ 11.9 98
12+12+15 Wall Wall Duct — 7.00 7.00 10.00 — 24.00 14.20 ~ 27.00 2000 1040 ~ 2550 9.8 5.1 ~ 12.5 98
12+12+15 Wall Duct Wall — 7.00 7.00 10.00 — 24.00 14.10 ~ 27.00 1960 950 ~ 2510 9.6 4.7 ~ 12.3 98
12+12+15 Wall Duct Duct — 7.00 7.00 10.00 — 24.00 13.80 ~ 26.30 2180 1080 ~ 2630 10.7 5.3 ~ 12.9 98
12+12+15 Duct Duct Wall — 7.00 7.00 10.00 — 24.00 13.60 ~ 26.30 2140 1000 ~ 2590 10.5 4.9 ~ 12.7 98
12+12+15 Duct Duct Duct — 7.00 7.00 10.00 — 24.00 13.30 ~ 25.90 2320 1120 ~ 2710 11.4 5.5 ~ 13.3 98
Combination
of
indoor unit
Type of indoor unit
Capacity of each indoor unit
Each capacity (kBtu/h) Total capacity (kBtu/h) Total input (W) Total current (A)
Power
factor (%)
A room B room C room — A room B room C room — Rating (min ~ max) Rating (min ~ max) Rating (min ~ max) Rating
Note:
1. Cooling capacity is based on 80°FDB (26.7°CDB) / 67°FWB (19.4°CWB) (Indoor temperature), 95°FDB
(35°CDB) / 75°FWB (24°CWB) (Outdoor temperature).
Heating capacity is based on 70°FDB (21°CDB) / 60°FWB (15.6°CWB) (Indoor temperature), 47°FDB
(8.3°CDB) / 43°FWB (6°CWB) (Outdoor temperature).
2. The total ability of connected indoor units is up to 39.0 kBtu/h.
3. It is impossible to connect only one indoor unit.
4. Wall type of indoor unit: CTXS-L, FTXS-L series
Duct type of indoor unit: CDXS-L, FDXS-L series
3D078955
3D078956
3D078957
3D078958
