Daikin SUPER MULTI NX G Series User Manual

Specifications EDUS121131
14 SUPER MULTI NX 2/3/4MXS-G/J Series Heat Pump
Cooling [60 Hz, 230 V]
Heating [60 Hz, 230 V]
Note:
1. Cooling capacity is based on 80°FDB (26.7°CDB) / 67°FWB (19.4°CWB) (Indoor temperature), 95°FDB
(35°CDB) / 75°FWB (24°CWB) (Outdoor temperature).
Heating capacity is based on 70°FDB (21°CDB) / 60°FWB (15.6°CWB) (Indoor temperature), 47°FDB
(8.3°CDB) / 43°FWB (6°CWB) (Outdoor temperature).
2. The total ability of connected indoor units is up to 18.0 kBtu/h.
3. It is impossible to connect only one indoor unit.
4. Wall type of indoor unit: CTXS-L, FTXS-L series
Duct type of indoor unit: CDXS-L, FDXS-L series
3D058841B
3D066341
Combination
of
indoor unit
Type of indoor unit
Capacity of each indoor unit
Each capacity (kBtu/h) Total capacity (kBtu/h) Total input (W) Total current (A)
Power
factor (%)
A room B room — — A room B room — — Rating (min ~ max) Rating (min ~ max) Rating (min ~ max) Rating
07 Wall — — — 7.00 — — — 7.00 5.50 ~ 7.60 500 330 ~ 560 2.3 1.5 ~ 2.5 96
09 Wall — — — 9.00 — — — 9.00 5.50 ~ 9.30 750 330 ~ 780 3.4 1.5 ~ 3.5 96
09 Duct — — — 8.00 — — — 8.00 5.00 ~ 8.00 830 390 ~ 830 3.8 1.8 ~ 3.8 96
07+07 Wall Wall — — 7.00 7.00 — — 14.00 6.70 ~ 15.00 920 350 ~ 1020 4.0 1.5 ~ 4.5 99
07+09 Wall Wall — — 7.00 9.00 — — 16.00 6.70 ~ 17.00 1150 350 ~ 1280 5.1 1.5 ~ 5.6 99
07+09 Wall Duct — — 6.56 8.44 — — 15.00 6.40 ~ 15.50 1260 420 ~ 1330 5.5 1.8 ~ 5.8 99
09+09 Wall Wall — — 9.00 9.00 — — 18.00 6.70 ~ 19.00 1420 350 ~ 1700 6.2 1.5 ~ 7.5 99
09+09 Wall Duct — — 8.50 8.50 — — 17.00 6.40 ~ 17.50 1600 420 ~ 1750 7.0 1.8 ~ 7.7 99
09+09 Duct Duct — — 8.00 8.00 — — 16.00 6.10 ~ 16.10 1760 490 ~ 1800 7.7 2.2 ~ 7.9 99
Combination
of
indoor unit
Type of indoor unit
Capacity of each indoor unit
Each capacity (kBtu/h) Total capacity (kBtu/h) Total input (W) Total current (A)
Power
factor (%)
A room B room — — A room B room — — Rating (min ~ max) Rating (min ~ max) Rating (min ~ max) Rating
07 Wall — — — 8.60 — — — 8.60 5.90 ~ 9.20 660 440 ~ 710 2.9 2.0 ~ 3.1 98
09 Wall — — — 11.00 — — — 11.00 5.90 ~ 11.80 910 440 ~ 980 4.0 2.0 ~ 4.3 98
09 Duct — — — 11.00 — — — 11.00 5.60 ~ 11.50 980 490 ~ 1050 4.3 2.2 ~ 4.7 98
07+07 Wall Wall — — 8.60 8.60 — — 17.20 8.20 ~ 18.80 1290 530 ~ 1430 5.7 2.3 ~ 6.3 99
07+09 Wall Wall — — 8.58 11.02 — — 19.60 8.20 ~ 21.40 1550 530 ~ 1710 6.8 2.3 ~ 7.5 99
07+09 Wall Duct — — 8.58 11.02 — — 19.60 8.10 ~ 21.00 1670 580 ~ 1890 7.3 2.5 ~ 8.3 99
09+09 Wall Wall — — 11.00 11.00 — — 22.00 8.20 ~ 24.00 1880 530 ~ 1970 8.3 2.3 ~ 8.7 99
09+09 Wall Duct — — 11.00 11.00 — — 22.00 8.10 ~ 23.60 2080 580 ~ 2130 9.1 2.5 ~ 9.4 99
09+09 Duct Duct — — 11.00 11.00 — — 22.00 8.00 ~ 23.20 2190 640 ~ 2290 9.6 2.8 ~ 10.1 99

Daikin SUPER MULTI NX G Series Specifications

General

Brand	Daikin
Model	SUPER MULTI NX G Series
Category	Air Conditioner
Language	English
