Names of Parts
Remote Controller
Signal transmitter
Receiver
To use the remote controller, aim the •
transmitter at the indoor unit. If there
is anything to block signals between
the unit and the remote controller,
such as a curtain, the unit will not
operate.
Do not drop the remote controller. Do •
not get it wet.
The maximum distance for •
communication is approximately 23ft
(7m).
FAN setting button
Selects the airfl ow rate setting. •
POWERFUL button
POWERFUL operation. •
Display (LCD)
Displays the current settings.•
(In this illustration, each section is
shown with all its displays on for the
purpose of explanation.)
TEMPERATURE
adjustment buttons
Changes the temperature setting.•
ON/OFF button
Press this button once to start •
operation.
Press once again to stop it.
Front cover
Open the front cover. •
<ARC452A21>
Page 14
Page 17
Page 12
Page 11
Page 8
To Next Page
