EDUS121131 CDXS, FDXS Series
Operation Manual 407
3
6
Outdoor Unit
Appearance of the outdoor unit may differ from some models.•
Refrigerant piping and
inter-unit wiring
Ground terminal
Inside this cover.•
Drain hose
Air inlet
(back and side)
Air outlet
Outdoor temperature
sensor (back)
Model name plate
