Daikin VRV III - Page 247

Accessories ED34-862
242 FXSQ-M
Duct Style Installation
 FXSQ63M
 FXSQ80~125M
JC : DU826-208F
Note)
1. When optional accessory other than these kits will be built in, refer to the
external drawing with optional accessories.
2. Parts names ~ show optional accessories.
Number
Suction flange
Discharge outlet flange
Long life filter for rear-suction type
High efficiency filter
Rear-suction sealing plate
Rear-suction type filter chamber
Access panel
Built-in Hi type body
Name
(with rear-suction sealing plate)
Description
Discharge outlet details
12-φ7 hole
4- key shape hole
30-φ4.7 hole
14-φ7 hole
36-φ4.7 hole
(Opening on
a ceiling)
(Opening on
a ceiling)
A view
Suction flange
(filter chamber for rear-suction type) details
540 or more
Required
installation
space
At installation of suction flange Suction flange details
36-φ4.7 hole
14-φ7 hole
4- key shape hole
JC : DU828-216F
Note)
1. When optional accessory other than these kits will be built in, refer to the
external drawing with optional accessories.
2. Parts names ~ show optional accessories.
Number
Suction flange
Discharge outlet flange
Long life filter for rear-suction type
High efficiency filter
Rear-suction sealing plate
Rear-suction type filter chamber
Access panel
Built-in Hi type body
Name
(with rear-suction sealing plate)
Description
Discharge outlet details
16-φ7 hole
4- key shape hole
40-φ4.7 hole
18-φ7 hole
48-φ4.7 hole
(Opening on
a ceiling)
(Opening on
a ceiling)
A view
Suction flange
(filter chamber for rear-suction type) details
At installation of suction flange Suction flange details
48-φ4.7 hole
20-φ7 hole
4- key shape hole
540 or more
Required
installation
space
