Daikin WGZ030DW - Physical and Electrical Data; Physical Data Tables

36 IM 1131-2
Electrical Data
Panel Ratings
Units without Supplemental Overloads
Standard Panel
Optional High Short Circuit Current Rating Panel
Units with Supplemental Overloads
Standard Panel
Optional High Short Circuit Current Rating Panel
Voltage Hz
WGZ-D Model Size
WGZ 030-040 WGZ 045-090 WGZ 100-200
208-230 60 5 5 10
380 60 5 5 5
400 50 5 5 5
460 60 5 5 5
575 60 5 5 5
Voltage Hz
Options, Single-Point
Power Connection Only
208-230 60 100
380 60 65
400 50 65
460 60 65
575 60 Not Available
Voltage Hz
WGZ-D Model Size
WGZ 030-040 WGZ 045-090 WGZ 100-200
208-230 60 5 5 10
380 60 5 5 5
400 50 5 5 5
460 60 5 5 5
575 60 5 5 5
Voltage Hz
Options, Single-Point
Power Connection Only
208-230 60 100
380 60 65
400 50 65
460 60 65
575 60 Not Available
