Daikin WGZ030DW - Condenserless Unit Dimensions and Weights

IM 1131-2 25
Lifting and Mounting Weights
Lifting and Mounti ng Weights
Figure 1: Lifting Locations, WGZ030-060D Packaged
Table 1: Lifting Weights, WGZ030-060D Packaged
Figure 2: Lifting Locations, WGZ070-130D Packaged
Table 2: Lifting Weights, WGZ070-130D Packaged
L1/M1 L2/M2
L3/M3
L4/M4
CONTROL BOX
WATER
CONNECTIONS
L1 L2 L3 L4 M1 M2 M3 M4
605 632 598 572 624 652 617 590 2408 2484
(274) (287) (271) (259) (283) (296) (280) (268) (1092) (11127)
629 644 614 601 649 664 633 619 2488 2564
(285) (292) (279) (273) (294) (301) (287) (281) (1129) (1163)
634 656 627 606 657 680 650 628 2523 2615
(288) (298) (284) (275) (298) (308) (295) (285) (1144) (1186)
634 664 635 606 657 688 658 628 2539 2631
(288) (301) (288) (275) (298) (312) (299) (285) (1152) (1193)
646 683 656 621 674 713 685 648 2606 2719
(293) (310) (298) (282) (306) (323) (311) (294) (1182) (1233)
644 690 664 620 672 720 693 647 2618 2731
(292) (313) (301) (281) (305) (327) (314) (293) (1188) (1239)
646 706 682 624 674 736 711 651 2658 2771
(293) (320) (309) (283) (306) (334) (323) (295) (1206) (1257)
OPER. WT
LBS (KG)
WGZ040DW
WGZ045DW
WGZ060DW
LIFTING WEIGHT FOR EACH POINT LBS (KG) MOUNTING LOADS FOR EACH POINT LBS (KG)
WGZ050DW
WGZ030DW
WGZ035DW
SHIP WT
LBS (KG)
MODEL
WGZ055DW
CONTROL BOX
WATER
CONNECTIONS
L3/M3
L2/M2L1/M1
L4/M4
CERTIFIED, WGZ070-130D
*333611601003* p3/3
L1 L2 L3 L4 M1 M2 M3 M4
877 843 900 935 912 877 935 973 3555 3696
(398) (382) (408) (424) (414) (398) (424) (441) (1613) (1676)
1016 900 965 1090 1056 935 1003 1133 3971 4128
(461) (408) (438) (494) (479) (424) (455) (514) (1801) (1872)
1026 824 1020 1270 1071 860 1064 1325 4140 4320
(465) (374) (463) (576) (486) (390) (483) (601) (1878) (1960)
1018 763 1084 1446 1066 799 1135 1515 4311 4515
(462) (346) (492) (656) (484) (362) (515) (687) (1955) (2048)
984 769 1087 1390 1032 806 1139 1457 4230 4434
(446) (349) (493) (630) (468) (366) (517) (661) (1919) (2011)
1046 824 1173 1490 1093 861 1226 1557 4533 4737
(475) (374) (532) (676) (496) (391) (556) (706) (2056) (2149)
SHIP WT
LBS (KG)
OPER. WT
LBS (KG)
WGZ070DW
WGZ080DW
WGZ100DW
WGZ115DW
MODWEL
WGZ130DW
MOUNTING LOADS FOR EACH POINT LBS (KG)LIFTING WEIGHT FOR EACH POINT LBS (KG)
WGZ090DW
