Vibration Isolators

Vibration Isolat ors

It is recommended that isolators be used on all upper level

installations or in areas where vibration transmission is a

consideration.

Figure 7: Isolator Locations

Transfer the unit as indicated under "Moving the Unit." In all

cases, set the unit in place and level with a spirit level. When

spring-type isolators are required, install springs running under

the main unit supports.

The unit should be set initially on shims or blocks at the listed

spring free height. When all piping, wiring, flushing, charging,

etc., is completed, the springs are adjusted upward to loosen

the blocks or shims that are then removed.

A rubber anti-skid pad should be used under isolators if hold-

down bolts are not used.

Installation of spring isolators requires flexible piping

connections and at least three feet of flexible electrical conduit

to avoid straining piping and transmitting vibration and noise.

Refer to unit dimension drawing for mounting locations.

Table 7: Isolator Kit Part Numbers

Table 8: Vibration Isolator Mounting Locations (Packaged Chillers)

Control Panel

Water

Connections

FRF

WGZ-DW Packaged Chiller Isolator Kit Part Numbers

Model Num be r 030-060 070-080 90 100-130 150-200

Spring-Flex

332320501 332320502 332320503 332320504 332320505

R-I- S

332325501 332325502 332325502 332325503 332325503

WGZ-DA Remote Condenser Isolator Kit Part Numbers

Model Num ber 030-060 070-080 090-115 130 150-200

Spring-Flex

332320506 332320507 332320508 332320509 332320510

R-I- S

332325504 332325501 332325501 332325501 332325505

Unit

Size M1 M2 M3 M4 M1 M2 M3 M4
