IM 1131-2 27
Lifting and Mounting Weights
Figure 5: Lifting Locations, WGZ070-130D Condenserless
Table 5: Lifting Weights, WGZ070-130D Condenserless
Figure 6: Lifting Locations, WGZ150-200D Condenserless
Table 6: Lifting Weights, WGZ150-200D Condenserless
.75
ISOLATOR HOLES IN THE
BOTTOM OF THE BASE
19
21.0
533
95.0
2413
21.0
533
30.0
762
2.0
51
2.0
51
CIRCUIT 1CIRCUIT 2
EVAP. WATER
CONNECTIONS
CONTROL BOX
L4
L1 L2
L3
M1
M2
M3
M4
CERT. WGZ070-130D, LESS COND
*333611611003*
L1 L2 L3 L4 M1 M2 M3 M4
431 503 552 472 565 700 571 461 1958 2296
(196) (228) (250) (214) (256) (318) (259) (209) (888) (1041)
600 631 691 657 705 755 615 575 2579 2649
(272) (286) (313) (298) (320) (343) (279) (261) (1170) (1202)
630 651 722 699 743 778 643 614 2701 2778
(286) (295) (328) (317) (337) (353) (292) (279) (1225) (1260)
658 684 764 735 777 820 681 646 2841 2923
(299) (310) (347) (333) (352) (372) (309) (293) (1289) (1326)
617 681 784 710 722 828 709 619 2792 2878
(280) (309) (356) (322) (328) (376) (322) (281) (1266) (1305)
705 764 845 780 828 925 761 682 3094 3196
(320) (347) (383) (354) (376) (420) (345) (309) (1403) (1450)
SHIP WT
LBS (KG)
OPER. WT
LBS (KG)
MOUNTING LOADS FOR EACH POINT LBS (KG)LIFTING WEIGHT FOR EACH POINT LBS (KG)
WGZ115DA
WGZ130DA
WGZ070DA
WGZ080DA
WGZ090DA
WGZ100DA
MODEL
21.0
533
54.0
1372
58.0
1473
21.0
533
2.0
51
2.0
51
30.0
762
.75
ISOLATOR HOLES IN THE
BOTTOM OF THE BASE
19
M1
L1
L2
M2 M3
L3
M4
L4
M5M6
CONTROL BOX
CIRCUIT 1CIRCUIT 2
CERT. WGZ150-200D, LESS COND.
*333611711003* 3/3
L1 L2 L3 L4 M1 M2 M3 M4 M5 M6
912 952 1127 1080 671 713 758 860 809 761 4071 4571
(414) (432) (511) (490) (304) (323) (344) (390) (367) (345) (1847) (2073)
1003 994 1170 1180 747 754 760 868 860 853 4347 4841
(455) (451) (531) (535) (339) (342) (345) (394) (390) (387) (1972) (2196)
1090 1065 1228 1257 796 791 785 914 921 927 4640 5134
(494) (483) (557) (570) (361) (359) (356) (415) (418) (421) (2105) (2329)
SHIP WT
LBS (KG)
LIFTING WEIGHT FOR EACH POINT (LBS)
OPER. WT
LBS (KG)
MOUNTING LOADS FOR EACH POINT LBS (KG)
WGZ170DA
WGZ200DA
MODEL
WGZ150DA
