Daikin WGZ030DW - Page 26

26 IM 1131-2
Lifting and Mounting Weights
Figure 3: Lifting Locations, WGZ150-200D Packaged
Table 3: Lifting Weights, WGZ150-200D Packaged
Figure 4: Lifting Locations, WGZ030-060D Condenserless
Table 4: Lifting Weights, WGZ030-060D Condenserless
EVAP. OUTLET
EVAP. INLET
CONTROL BOX
WATER
CONNECTIONS
L4/M4
L1/M1
L3/M3
L2/M2
L1 L2 L3 L4 M1 M2 M3 M4
1490 1393 1444 1545 1691 1581 1638 1752 5873 6662
(676) (632) (655) (701) (767) (717) (743) (795) (2664) (3022)
1661 1439 1521 1756 1880 1628 1720 1986 6377 7214
(753) (653) (690) (797) (853) (738) (780) (901) (2893) (3272)
1729 1492 1599 1852 1946 1679 1799 2085 6672 7509
(784) (677) (725) (840) (883) (762) (816) (946) (3026) (3406)
WGZ150DW
WGZ170DW
WGZ200DW
MODWEL
LIFTING WEIGHT FOR EACH POINT LBS (KG) MOUNTING LOADS FOR EACH POINT LBS (KG) SHIP WT
LBS (KG)
OPER. WT
LBS (KG)
21.0
533
95.0
2413
21.0
533
2.0
51
30.0
762
2.0
51
.75
ISOLATOR HOLES ARE IN
THE BOTTOM OF THE BASE
19
CONTROL BOX
EVAP. WATER
CONNECTIONS
CIRCUIT 1CIRCUIT 2
L4
L1
M4
M1
M2
L2
L3
M3
WGZ030-060D, LESS COND
*333611511002* p 2 of 2
L1 L2 L3 L4 M1 M2 M3 M4
415 430 373 360 476 501 322 306 1578 1604
(188) (195) (169) (163) (216) (227) (146) (139) (716) (728)
440 444 391 387 508 515 336 331 1662 1690
(200) (201) (177) (176) (230) (234) (152) (150) (754) (767)
435 446 399 389 502 521 345 332 1669 1699
(197) (202) (181) (176) (228) (236) (156) (151) (757) (771)
435 454 406 389 501 533 353 332 1685 1719
(197) (206) (184) (176) (227) (242) (160) (151) (764) (780)
437 460 413 392 503 542 361 335 1702 1740
(198) (209) (187) (178) (228) (246) (164) (152) (772) (789)
435 467 420 392 500 553 369 333 1714 1755
(197) (212) (191) (178) (227) (251) (167) (151) (778) (796)
438 475 431 397 503 565 380 338 1741 1786
(199) (216) (196) (180) (228) (256) (172) (153) (790) (810)
SHIP WT
LBS (KG)
OPER. WT
LBS (KG)
LIFTING WEIGHT FOR EACH POINT LBS (KG) MOUNTING LOADS FOR EACH POINT LBS (KG)
WGZ055DA
WGZ060DA
MODEL
WGZ030DA
WGZ035DA
WGZ040DA
WGZ045DA
WGZ050DA
