52 IM 1131-2
Electrical Data
Table 39: Connection Sizing - Multi-Point with optional External Overloads (continued)
Note [1]: On HSCCR Unit = 400A {(1) 600 - #1}
Note [2]: Power Block and Disconnect Switch sizes are the minimum. Larger sizes may be used, however lug range must be same.
Model Voltage
Size Size Size Lug Range Size Lug Range Size Lug Range Size Lug Range
208V 175A (1) 2/0 - #14 250A (1) 350 - #6 175A (1) 2/0 - #14 250A (1) 350 - #6
230V 175A (1) 2/0 - #14 125A [1] (1) 3/0 - #3 175A (1) 2/0 - #14 125A [1] (1) 3/0 - #3
380V 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
400-460V 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
575V 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
208V 175A (1) 2/0 - #14 250A (1) 350 - #6 175A (1) 2/0 - #14 250A (1) 350 - #6
230V 175A (1) 2/0 - #14 125A [1] (1) 3/0 - #3 175A (1) 2/0 - #14 125A [1] (1) 3/0 - #3
380V 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
400-460V 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
575V 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
208V 175A (1) 2/0 - #14 250A (1) 350 - #6 175A (1) 2/0 - #14 250A (1) 350 - #6
230V 175A (1) 2/0 - #14 250A (1) 350 - #6 175A (1) 2/0 - #14 250A (1) 350 - #6
380V 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
400-460V 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
575V 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
208V 175A (1) 2/0 - #14 250A (1) 350 - #6 175A (1) 2/0 - #14 250A (1) 350 - #6
230V 175A (1) 2/0 - #14 250A (1) 350 - #6 175A (1) 2/0 - #14 250A (1) 350 - #6
380V 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
400-460V 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
575V 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
208V 380A (1) 500 - #4 250A (1) 350 - #6 380A (1) 500 - #4 250A (1) 350 - #6
230V 380A (1) 500 - #4 250A (1) 350 - #6 380A (1) 500 - #4 250A (1) 350 - #6
380V 175A (1) 2/0 - #14 125A [1] (1) 3/0 - #3 175A (1) 2/0 - #14 125A [1] (1) 3/0 - #3
400-460V 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
575V 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
208V 380A (1) 500 - #4 250A (1) 350 - #6 380A (1) 500 - #4 250A (1) 350 - #6
230V 380A (1) 500 - #4 250A (1) 350 - #6 380A (1) 500 - #4 250A (1) 350 - #6
380V 175A (1) 2/0 - #14 250A (1) 350 - #6 175A (1) 2/0 - #14 250A (1) 350 - #6
400-460V 175A (1) 2/0 - #14 125A [1] (1) 3/0 - #3 175A (1) 2/0 - #14 125A [1] (1) 3/0 - #3
575V 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10
208V 380A (1) 500 - #4 250A (1) 350 - #6 380A (1) 500 - #4 400A (2) 500 - 3/0
230V 380A (1) 500 - #4 250A (1) 350 - #6 380A (1) 500 - #4 400A (2) 500 - 3/0
380V 175A (1) 2/0 - #14 250A (1) 350 - #6 175A (1) 2/0 - #14 250A (1) 350 - #6
400-460V 175A (1) 2/0 - #14 125A [1] (1) 3/0 - #3 175A (1) 2/0 - #14 250A (1) 350 - #6
575V 175A (1) 2/0 - #14 100A [1] (1) 1/0 - #10 175A (1) 2/0 - #14 125A [1] (1) 3/0 - #3
208V 380A (1) 500 - #4 400A (2) 500 - 3/0 380A (1) 500 - #4 400A (2) 500 - 3/0
230V 380A (1) 500 - #4 400A (2) 500 - 3/0 380A (1) 500 - #4 400A (2) 500 - 3/0
380V 175A (1) 2/0 - #14 250A (1) 350 - #6 175A (1) 2/0 - #14 250A (1) 350 - #6
400-460V 175A (1) 2/0 - #14 250A (1) 350 - #6 175A (1) 2/0 - #14 250A (1) 350 - #6
575V 175A (1) 2/0 - #14 125A [1] (1) 3/0 - #3 175A (1) 2/0 - #14 125A [1] (1) 3/0 - #3
090D
100D
115D
130D
150D
170D
200D
080D
Cir #1
Power Block [2]
Cir #1
Disconnect Sw [2]
Cir #2
Power Block [2]
Cir #2
Disconnect Sw [2]
