DAITEM MHF02X - 8.2 When Not Communicating

17
Activate the outdoor
caller unit
Status display
on the handset (1)
Side gate access status
1. Hold the tag in front of the
name label.
2. Press (3).
Closed
1. Or enter the access code
(2).
Mr et Mme Evêque-Mourroux
C
Mr et Mme Evêque-Mourroux
3. The side gate is unlocked
within 5 seconds.
Open
C
(1) If a position contact is connected.
(2) If you press the wrong button, press then enter the access code again.
(3) Only applies to the outdoor caller unit with keypad. If the AUTO COMMAND parameter (see
ACCESS/PARAMETERS/AUTO COMMAND menu) is set to ELECTRIC STRIKE, the side gate is opened as soon as
the tag is held up to the caller unit or the access code is entered. There is then no need to press .
8.2.1 Using the outdoor caller unit with keypad
8.2 When not communicating
