Dake SE712 - Page 24

Dake Corporation
724 Robbins Road
Grand Haven, MI 49417
www.dakecorp.com
23 REV022019
Item
Part No.
Ref No.
Part Name
Qty
88
301694
181852
Coupler (3/8” PT)
1
89
-
181601
Hose Clip (Ø5)
2
90
301456
181981
Hose (OD 12mm x ID 8mm x 200mm)
1
91
301455
181856
Valve (1/8” PT)
1
Not
Shown
302219 181308 Adjustable feet (optional) 2
94
301535
181128
Wheel Rod
2
95
300742
181129
Wheel
4
96
301536
HP210
Cotter Pin (Ø3 x 25mm)
4
97
300730
181304-2
Cylinder Complete Set
1
99
43632
W017
Washer (5/16”)
3
100
43315
S017
Hex. Head Screw (5/16-18 x 1”)
9
101 43334 S412
Hex. Socket Head Screw
(3/8”-16 x 2-1/4”)
1
102
43633
W013
Washer (3/8”)
3
112
-
-
Hex. Head Screw
1
113
300952
181242B
Brush Support
1
114
43627
W007
Washer (3/16”-12)
2
115 43881 S708
Cross Round Head Screw
(#10-24 x 3/8”)
2
116
301695
192029
Bearing Spacer
1
117
301696
181307
Bushing
1
118 78744 HS422
Hex. Socket Headless Screw
(M6 x 10mm)
1
- 301620 181241BS
Brush assembly,
items 112-118,120, & 258
1
120
300951
192030
Spring for brush
1
130
N/A
181306
Bracket (for CE only)
1
131 N/A HS508
Cross Round Head Screw
(For CE only) (M4 x 5)
4
132
N/A
181305
Switch Base (For CE only)
1
133
N/A
HW003
Washer (For CE only) (M5)
2
134 N/A HW509
Cross Round Head Screw
(For CE only) (M4 x 10)
1
201
300749
181216-1
Gear Box
1
201
300749R
-
Rebuilt Gear Box
1
202
301473
181223
Worm Shaft
1
203
300957
K008
Key (5mm x 5mm x 30mm)
1
204
300853
CA6003LLU
Bearing
3
205
301476
181224
Bearing Bushing
1
207
300495
C002
C-Retainer ring (17mm)
1
208
70256
S607
Socket Set Screw (5/16”-18 x 5/16”)
1
209
300958
181226
Spindle Pulley
1
210 301451 S604
Hex. Socket Headless Screw
(M6-1.0 x 6mm)
2
