Dake SE712 - Page 25

Dake Corporation
724 Robbins Road
Grand Haven, MI 49417
www.dakecorp.com
24 REV022019
Item
Part No.
Ref No.
Part Name
Qty
211
300747
181874
Belt
1
212 43303 -
Cross Socket Hex. Head Screw
(1/4”-20 x 5/8”)
4
213 301451 S604
Hex. Socket Headless Screw
(M6-1.0 x 6mm)
2
214
301697
181222-1
Gear Box Cover
1
215
301698
181221
Gear Box Gasket
1
216
301468
HK025
Key
2
217
301683
181220-1
Worm Gear
1
218
301467
181219-1
Transmission Wheel Shaft
1
219
76827
HCS13
C-Retainer Ring (Ø1”)
1
221
301471
181218-1
Bushing
1
222
300693
CA6205LU
Bearing
2
223
301699
181217-1
Bushing
1
225
301700
181246
Bearing Cover
1
226
300905
S712
Cross Round Head Screw (5/32” x 3/8”)
3
227
300946
181203-1
Body Frame
1
228
43633
W204
Spring Washer (3/8”)
4
229 43330 S013
Hex. Socket Head Screw
(3/8”-16 x 1-1/4”)
4
Not
Shown
- - C-Retainer ring (26 PT)
231
300947
181214-2
Drive Wheel
1
232
43314
S022
Hex. Head Screw (5/16”-18 x 3/4”)
1
234 -
236
301730 -
Wheel Shaft Assembly
(234, 235, & 236)
234
-
HP013
Pin (Ø4mm x 22mm)
1
235
-
181208
Sliding Plate Draw Block
1
236
-
181209
Blade Wheel Shaft
1
237
300934
181210
Sliding Plate OR 300737
2
238
300933
181211
Blade Tension Sliding Block
1
239 43433 S608
Hex. Socket Headless Screw
(5/16”-18 x 3/4")
1
240
43317
S019
Hex. Head Screw (5/16”-18 x 1-1/2”)
2
241
43632
W015
Washer (5/16”)
2
242
43644
W205
Lock Washer (5/16”)
2
243
43315
S020
Hex. Head Screw (5/16-18 x 1”)
2
244
301703
181212
Spring
1
245
301704
181213
Blade Adjustable Knob
1
246
301705
181207-1
Bushing
1
247
302799
HCR04
C-Retainer ring (35 PT)
1
248
300734
CA6202Z
Bearing
2
250
300948
181205-2
Idler Wheel
1
251
300732
181894
Blade
1
252
43632
W017
Washer (5/16”)
1
