Adeo Control SGDD-C4-4
Manual
Rev. 1.6
Ad e o C o n t r o l i s a b r a n d o f A d e o G ro up s . r .l .
6 / 36
3. Characteristics
Tensione di alimentazione - Supply Voltage
12 / 24 / 48 Vdc
Corrente assorbita - Input Current
voltage
min
Typ*
max
@ 12Vdc
110mA (1,2W)
320mA (3,84W)
500mA
@ 24Vdc
60mA (1,44W)
160mA (3,84W)
@ 48Vdc
40mA (1,92W)
80mA (3,84W)
*ethernet and all bus at full load
Temperatura di stoccaggio - Storage temperature
min: -40 max: +60 °C
Temperatura di esercizio - Working temperature
min: -40 max: +40 °C
Grado di protezione - Protection Grade
PLASTIC BOX IP10
Peso - Weigth
ALUMINIUM BOX: 230g - PLASTIC BOX 125g
Dimensioni Meccaniche - Mechanical dimensions
ALUMINIUM BOX: 105x70x47 - PLASTIC BOX: DIN RAIL 4mod.
ETHERNET
10/100 Mbit baseT FULL DUPLEX AUTO NEGOTIATION
DMX
Max 512 ch (dipende dal cablaggio) open fail safe - short fail safe
DALI
Max 64 ch, alimentatore min 200mA – max 250mA integrato
Dimensioni meccaniche
72 x 92 x 62 mm
4. Reference Standards
EN 55015
Limits and methods of measurement of radio disturbance characteristics of electrical lighting and similar equipment
EN 61547
Equipment for general lighting purposes – EMC immunity requirements
EN 61347-1
Lamp controlgear – Part 1: General and safety requirements
IEC 62386-101 ED.2
Digital addressable lighting interface – Part 101: General requirement – System components
IEC 62386-103 ED.2
Digital addressable lighting interface – Part 103: General requirements – Control devices
IEC 62386-205 ED.2
1
Digital addressable lighting interface – Part 205: Particular requirements for control gear – Supply voltage controller for
incandescent lamps (device type 4)
IEC 62386-207 ED.2
2
Digital addressable lighting interface – Part 207: Particular requirements for control gear – LED modules (device type 6)
IEC 62386-209 ED.2
3
Digital addressable lighting interface – Part 209: Particular requirements for control gear – Colour control (device type 8)
ANSI E1.11
Entertainment Technology – USITT DMX512-A Asynchronous Serial Digital Data Transmission Standard for Controlling Lighting
Equipment and Accessories
1
L’SGDD-C4-4 provides commands for the DT4 control gears, compatible with IEC 62386-205
2
L’SGDD-C4-4 provides commands for the DT6 control gears, compatible with IEC 62386-207
3
L’SGDD-C4-4 provides commands for the DT8 control gears, compatible to IEC 62386-208 (colour type Tc, colour type RGBWAF)
