DANA BREVINI E Series - SHAFT TIGHTENING TORQUES

34
MECHANICAL INSTALLATION
Dana Incorporated IMM-0017EN - Installation and Maintenance Manual
8.2 SHAFT TIGHTENING TORQUES
Use the following table for shaft tightening torques.
Type Bolt Tightining Torque [Nm]
E.030 M5 5
E.040 M6 8
E.050 M10 20
E.063 M10 20
E.075 M12 30
E.080 M12 30
E.100 M16 40
E.125 M16 40
