6 Dana Incorporated IMM-0017EN - Installation and Maintenance Manual
2 HOW TO USE THIS MANUAL
Take attention to the following safety and warning signs for proper understanding and quick reference.
Table 1:
Hazard pictograms
Table 2:
The operating instructions contain important information to ensure;
• Trouble-free operation
• Fulfilment of any rights to claim under guarantee
The operating instruction must be kept close to the gearbox and must be available in case it is needed.
This operating instruction is written for D series gear units and is applicable only for D series. If any different type of gearbox is
used please ask Dana Motion Systems Italia S.r.l. for the operating instructions of that type.
This instruction can be used only for standard type geared units of Dana Motion Systems Italia S.r.l.. For special application
and modified gear units ask Dana Motion Systems Italia S.r.l. for validity.
This manual does not cover 94/9/EC compatible gearboxes. For 94/9/EC contact Dana Motion Systems Italia S.r.l..
Indicates an imminently hazardous situation which, if
not avoided, will result in death or serious injury.
Indicates an imminently hazardous situation which, if
not avoided, could result in death or serious injury.
Indicates a situation which, if not avoided, may result
in damage to components.
Indicates information which may make product service
easier to perform.
NOTE:
Important Information.
General danger
Electric current
Moving parts
NOTE:
EC Machinery Directive:
Within terms of the EC machinery directive 2006/42/EC, the gearboxes are considered as not autonomous machine, but
as a component to install in machines.
Operation is prohibited within the area of validity of the EC directive, until it has been determined that the machine, in
which this product is installed, corresponds to the regulations within this directive.
