DANA BREVINI K Series

Questions and Answers

J
Jennifer SmithAug 26, 2025
What causes oil to leak from my DANA Engine gearbox?
- R
  Rachel YoungAug 27, 2025
  Oil leaks can stem from several causes. If the ambient temperature is over +40 Celsius or the gearbox works non-stop for over 16 hours, replace the top plug with a breather plug, referring to the manual for proper usage. If that's not the case, the seal might be damaged. If you're using a breather plug, ensure it's correctly positioned at the top according to your mounting position and that the plug is sufficiently tight. Clean the plug and the rubber surface underneath it. If the oil is leaking from the housing itself, it may have a micro split or crack. If the oil leakage is from the cover, the sealing liquid under the cover may be split or defective; in this case, disassemble the cover, apply new sealing liquid, reassemble the cover, and tighten the bolts.
A
Amber TurnerAug 28, 2025
Why is my DANA Engine motor heating up?
- B
  Barbara PonceAug 28, 2025
  A motor can overheat for a couple of reasons. It might be running over its nominal current, indicating that the motor power is insufficient or that it's experiencing some overload. The motor itself may also be defective. Another cause could be a dusty environment. Check the motor fan hub and ribs to ensure they are free of dust. If you're using a forced external fan, verify that it is working. If you're using a frequency inverter at low speeds without a forced external fan, you might need one.
N
Nicholas WheelerAug 30, 2025
What to do if my DANA Engine gearbox is stopping too late?
- J
  Juan YoungAug 30, 2025
  Check the wiring diagram of the brake. There are two different kinds of brake wiring diagrams. The standard gearbox delivered from our factory is set to delayed braking. For sudden braking check the wiring diagram.
T
Todd BenjaminSep 1, 2025
Why does my DANA Engine gearbox move regularly on its mounting point?
- Q
  qbrownSep 1, 2025
  The movement of the gearbox is due to the runout of the shaft to which the gearbox is assembled. This is normal and does not harm the gearbox unless you are using a torque arm.
A
Amy LopezSep 3, 2025
Why does my DANA Engine gearbox move randomly on its mounting point?
- J
  James LiSep 3, 2025
  The movement of the gearbox is because of the runout and clearance of the shaft which you assemble the gearbox. Check the clearance of the assembling shaft and the clearances on your machine. This has no bad affect or harm to the gearbox unless you are using torque arm.
S
Sarah SandersSep 5, 2025
What to do if my DANA Engine gearbox does not start mornings or after a long stop?
- J
  Jeffrey PenaSep 5, 2025
  The oil may not be suitable for your working conditions. Try changing to lower viscosity oils, referring to this manual for correct oil selection. Another solution is to operate in higher ambient temperatures if possible. If the problem persists, you may need a higher motor power.
M
Michelle AlexanderSep 7, 2025
What causes a defect in my DANA Engine gearbox housing?
- J
  James DanielsSep 8, 2025
  The radial load or polygon effect of the chain may have caused the damage if you are using a chain drive or pinion gear. Check also if the assembly bolts are loosened or the plate you assemble the gearbox is rigid enough. Check if you are using the correct diameter of chain drive and you are not exceeding max. allowed radial load. Check the position of your output element and re-calculate your radial load and check if this fit to the maximum allowed radial load.
E
Emily DiazSep 10, 2025
What to do if my DANA Engine gearbox is starting too late?
- B
  Barbara HernandezSep 10, 2025
  For fast opening of big brakes (over 100Nm), you may need shock transformators which is supplied by Dana Motion Systems Italia S.r.l..
R
rwestSep 12, 2025
What causes a defect in my DANA Engine output shaft?
- K
  Kevin HallSep 12, 2025
  The radial load or polygon effect of the chain may have caused the damage if you are using a chain drive or pinion gear. Check also if the assembly bolts are loosened or the plate you assemble the gearbox is rigid enough. Check if you are using the correct diameter of chain drive and you are not exceeding max. allowed radial load. Check the position of your output element and re-calculate your radial load and check if this fit to the maximum allowed radial load.
B
Benjamin MeyerSep 14, 2025
What to do if my DANA Engine motor is running but the gearbox shaft does not turn?
- A
  Alvin LeblancSep 14, 2025
  Some part (key, gear) may be defect inside gearbox.
