MECHANICAL INSTALLATION
43Dana IncorporatedIMM-0018EN - Installation and Maintenance Manual
8.5 SHAFT TIGHTENING TORQUES VALUES ARE AS SHOWN
Type Bolt
Tightening
Torques [Nm]
K.00 M6 10
K.10 M10 48
K.20 M12 84
K.27 M12 84
K.28 M16 206
K.37 M16 206
K.47 M16 206
K.57 M20 415
K.67 M20 415
K.77 M24 714
K.87 M24 714
K.97 M24 714
