DANA BREVINI E Series - MOUNTING POSITIONS AND OIL QUANTITIES

44
LUBRICATION
Dana Incorporated IMM-0017EN - Installation and Maintenance Manual
10.3 MOUNTING POSITIONS
Figured mounting positions of M1 to M6 are determined as reference of directional position of the gearbox. Mounting surfaces
are not binding.
