MECHANICAL INSTALLATION
37Dana IncorporatedIMM-0017EN - Installation and Maintenance Manual
Assemble the parts as shown bellow
1Bolt
2Washer
3Bolt
4Torque arm
5 Machine Connection Arm
6Nut
