TROUBLESHOOTING GUIDE
Dana Incorporated IMM-0017EN - Installation and Maintenance Manual
019 Oil is Leaking Oil Leakage from Housing
Observe exactly where the oil is comming out. It could be seal or
plug point where it comes out and leakes over the housing. If this
is your case goto ID 018/019. If you are sure oil comes out from
housing than housing has some micro split / crack. Goto ID 100
020 Oil is Leaking Oil Leakage from Cover
The sealing liquit under cover is split/defect. Disassemle the cov-
er and put new sealing liquit. Assemle the cover and tighten the
bolts. If still same problem goto ID 100
021
Gearbox is moving regularly
on its mounting point
You are using Torque Arm
The movement of gear box is because of the runout of the shaft
which you assemle the gearbox. This has no bad affect or harm
to the gearbox and is normal unless you are using torque arm.
022
Gearbox is moving randomly
on its mounting point
You are using Torque Arm
The movement of gear box is because of the runout and clear-
ance of the shaft which you assemle the gearbox. Check the
clearance of the assemling shaft and the clearances on your ma-
chine. This has no bad affect or harm to the gearbox unless you
are using torque arm.
023 Motor is heating up
Motor is running over its nom-
inal current
The motor power is not enough or some overload to the motor is
possible. The motor may be defect. Goto ID 100
023 Motor is heating up Ambient is dusty
Check the motor Fan Hub and rips. They must be free of dust. If
you are using forced external fan, check if it is working. If you are
using frequency inverter in low speeds and you do not have
forced external fan, you may need forced external fan. Goto ID
100
024
Motor is running but Gearbox
shaft does not turn
Scratchinh noise comes out Some part (key, gear) may be defect inside gearbox. Goto ID 10
025 Gearbox Housing is Defect
You are using chain drive or
pinion gear
The radial load or poligon effect of the chain may have caused
the damage. Check also if the assembly bolts are loosened or the
plate you assemble the gearbox is rigit enough. Check if you are
using the correct diameter of chain drive and you are not exceed-
ing max. allowed radial load. Check the position of your output
element and re-calculate your radyal load and check if this fit to
the maximum allowed radial load. Goto ID 100
026 Output Shaft is Defect
You are using chain drive or
pinion gear
The radial load or poligon effect of the chain may have caused
the damage. Check also if the assembly bolts are loosened or the
plate you assemble the gearbox is rigit enough. Check if you are
using the correct diameter of chain drive and you are not exceed-
ing max. allowed radial load. Check the position of your output
element and re-calculate your radyal load and check if this fit to
the maximum allowed radial load. Goto ID 100
027 Gearbox is stopping too late You are using braked motor
Please check the wiring diagram of the brake. There are two dif-
ferent kind of brake wiring diagram. The standart gearbox deliv-
ered from our factory is set to delayed braking. For sudden
braking check the wiring diagram.
028 Gearbox is starting too late You are using braked motor
For fast opening of big brakes (over 100Nm), you may need
shock transformators which is supplied by Dana Motion Systems
Italia S.r.l.. Goto ID 100
100 Service Required No self solution found
Please contact Dana Motion Systems Italia S.r.l. Service point.
See on the back side of this manual. Changing mechanical parts
of gearbox can only be done by Dana Motion Systems Italia S.r.l.
or with information of Dana Motion Systems Italia S.r.l.. Any
change without informing Dana Motion Systems Italia S.r.l. will
cancel the waranty, manufacturer decleration and Dana Motion
Systems Italia S.r.l. will take no responsibility.
