17.2. Possible error messages
The following table lists possible error messages appearing within
the Web Remote interface ordered by the error Id.
Id Display text Eventlog text Description Location Possible reasons
10 System error 8 System error %u
(Reboot)
Unexpected CPU
reset
DSP Software or
hardware error.
11 System error 128 System error %d
(I2C, IC 0x%02X,
Pos %d)
Internal I2C
communication fault
DSP Any I2C device
defect.
15 Unknown device type Unknown device type
%d
Unknown device type
16 Invalid device ident Invalid device ident
%d
Invalid hardware
configuration
ADDAC, Amp, SMPS Missing or wrong
module identification.
17 Invalid CPLD version Invalid CPLD version
%d (minimum
required %d)
Invalid CPLD
identification
DSP Missing or wrong
CPLD identification.
18 Invalid ADDAC ident Invalid ADDAC
board ident %d
Invalid ADDAC
identification
ADDAC Missing or wrong
ADDAC
identification.
19 Invalid display ident Invalid display board
ident %d
Invalid DISPLAY
identification
DISPLAY Missing or wrong
DISPLAY
identification.
20 Program error %u Program error %d,
%d, %d, %d
Program error DSP Various.
21 Invalid DSP Data Invalid DSP database
(Position %d, Error
%d)
Invalid DSP data DSP Software error.
25 Program error %u Program error %d:
AWL error %d in
AWL %d, line %d
Program error DSP Various.
28 SMPS comm. error SMPS communication
error (status %04X)
SMPS communication
fault
DSP, SMPS DSP or SMPS defect,
cable defect.
29 SMPS firmware
mismatch
SMPS firmware V%d.
%02d.%02d not
suitable for hardware
ident %d
Invalid SMPS
configuration
SMPS SMPS firmware does
not match module
identification.
30 SMPS temp err %dÂ
°C
SMPS temperature
error %+3d°C
(power %uW)
Mega-Temp-Off
32 Mains overvoltage
>276V
Mains overvoltage
>276V (avg %3dV,
peak %3dV, status
%04X, err %04X)
Mains overvoltage
(External: Mains) Mains voltage is/was
too high.
34 Mains undervoltage
%dV
Mains undervoltage
(avg %3dV, peak
%3dV, status %04X,
err %04X)
Mains undervoltage
(External: Mains) Mains voltage is/was
too low.
45 Amp. comm. error Amp. communication
error (status %04X)
Amp communication
fault
DSP, Amp DSP or Amp defect.
