Fahrzeug-/Funktionsdecoder ab Firmware-Version 1.11
47
Locomotive/Locomotive function decoder from firmware version 3.12
CV
Name and definition Range
Standard
145
Conditions for LV (not relevant to PD*)
Function Value
Default value (always on, if function key on) 0
Only forward +1
Only backward +2
Only while standing +3
Only while driving +6
Only at F0 (light) off +9
Only at F0 (light) on +18
Not in shunting gear +27
Only in shunting gear +54
Ignore direction in shunting gear +81
Ignore driving/stand in shunting gear +108
Ignore direction and driving/stand in shunting gear +135
Always only one number of each definite range may be added up!
0-161 0
146
Conditions for LR (see CV145)
0-161 0
147 Conditions for AUX1 (see CV145) 0-161 0
148 Conditions for AUX2 (see CV145) 0-161 0
149 Conditions for AUX3 (see CV145) 0-161 0
150 Conditions for AUX4
(see CV145) 0-161 0
151 Conditions for AUX5 (see CV145) 0-161 0
152 Conditions for AUX6 (see CV145) 0-161 0
