Fahrzeug-/Funktionsdecoder ab Firmware-Version 1.11
46
Locomotive/Locomotive function decoder from firmware version 3.12
CV
Name and definition Range
Standard
138
Timer for approach (not relevant to PD*)
Each 100 ms, 0 = no driving away
0-250 0
139
Timer for waiting (not relevant to PD*)
Each 100 ms, 0 = no waiting
0-250 0
140
Timer for driving away (not relevant to PD*)
Each 100 ms, 0 = no driving away
0-250 0
141
Speed step for approach
(not relevant to PD*)
0-127 12
142
Speed step for driving away (not relevant to PD*)
0-127 12
143
Settings
(not relevant to PD*)
Bit Function Value
6........Deactivate coupling process and timer ............................................... 64
7........Coupling process only in shunting gear ............................................. 128
0-255 0
144 Settings
Bit Function Value
0........Dynamic channel usage ........................................................................1
1........Immediate starting after current interruption ........................................ 2
2........Special bit for lighting in analog operation .............................................4
3
........Brake section output to “GPIO“ ...........................................................8
(→1 = no brake section detected, 0 = braking)
(only relevant to DH21A/DH22A/FH22A)
4
........Brake with “GPIO“ ..............................................................................16
(1 = driving, 0 = braking)
(only relevant to DH21A/DH22A/FH22A)
0-31 0
