45
Fahrzeug-/Funktionsdecoder ab Firmware-Version 1.11
45
Locomotive/Locomotive function decoder from firmware version 3.12
CV
Name and definition Range
Standard
131
Function mapping low beam light (not relevant to PD*)
0 = deactivated, 1 … 28 = F1 … F28, 29 = F0 (light)
Only valid if CV137/Bit 4=1
0-29 8
132
Function mapping shunting gear (as CV131)
0-29 4
133
Function mapping deceleration off (as CV131)
0-29 9
134
Decision threshold for asymmetry
(see CV27)
Default value 6 corresponds approximately to 0.7 volt asymmetry and thus to the forward
voltage of a silicon diode.Values smaller 3 are not useful, values higher 6 on demand.
0-15 6
135
Multiplication speed check back signal
0 = deactivated
0-255 0
136
Division speed check back signal
0 = /1, 1 = /2, 2 = /4, 3 = /8, 4 = /16, 5 = /32, 6 = /64
0-6 0
137 Settings
Bit Function Value
0........Unamplified function outputs instead of ZCLK and ZDAT *) .................1
1........Switch off energy saving mode .............................................................2
2........Invert SUSI driving direction *) ..............................................................4
3
........Currently without function *)
...................................................................
4........Activate extended function mapping *)
...............................................16
(see CV131 and CV137/Bit 5)
5
........0 = AUX3 and AUX4 on ZCLK and ZDAT *) .........................................32
1 = AUX5 and AUX6 on ZCLK and ZDA
T *)
(Onlay valid if CV137/Bit 0=1)
*) (not relevant to PD*)
0-63 0
