D&H PD05A - Page 44

44
Fahrzeug-/Funktionsdecoder ab Firmware-Version 1.11
44
Locomotive/Locomotive function decoder from firmware version 3.12
CV
Name and definition Range
Standard
120
Timer for switch off AUX4
Each 100 ms, 0 = deactivated
0-250 0
121
Function mapping LV+LR on / AUX1+AUX2 off
Bit 0 = F1 … Bit 7 = F8
0-255 0
122
Function mapping AUX1+AUX2 on / LV+LR off
Bit 0 = F1 … Bit 7 = F8
0-255 0
123
Slow approach speed
(see CV27)
Only with suitable brake modules
0-127 63
124
Function mapping star
ting delay
(see CV63)
Bit 0 = F1 ... Bit 7 = F8
0-255
0
125
Switch off function for AUX3
Bit 0 = F1 … Bit 7 = F8
0-255 0
126
Switch off function for AUX4
Bit 0 = F1 … Bit 7 = F8
0-255 0
127
Switch off function for AUX5
Bit 0 = F1 … Bit 7 = F8
0-255 0
128 Switch off function for AUX6
Bit 0 = F1 … Bit 7 = F8
0-255 0
129 T
imer for switch off AUX5
Each 100 ms, 0 = deactivated
0-250 0
130 Timer for switch off AUX6
Each 100 ms, 0 = deactivated
0-250 0
