Fahrzeug-/Funktionsdecoder ab Firmware-Version 1.11
43
Locomotive/Locomotive function decoder from firmware version 3.12
CV
Name and definition Range
Standard
65
Maximum speed step in two part brake sections (see CV60)
Only with brake diode
0-127 12
66
Forward trim
0 = deactivated, smaller 128 = reduction, higher 128 = enhancement of the speed
0-255 0
95
Backward trim (see CV66)
0-255 0
105
User identification 1
0-255 0
106
User identification 2
0-255 0
112
Speed reduction analog (not relevant to FH*/PD05A)
0 = small reduction … 31 = strong reduction
0-31 15
113
Switch off function for LV
Bit 0 = F1 ... Bit 7 = F8
0-255 0
114
Switch off function for LR
Bit 0 = F1 ... Bit 7 = F8
0-255 0
115
Switch off function for AUX1
Bit 0 = F1 ... Bit 7 = F8
0-255 0
116 Switch off function for AUX2
Bit 0 = F1 ... Bit 7 = F8
0-255 0
117 Timer for switch off AUX1
Each 100 ms, 0 = deactivated
0-250 0
118 Timer for switch off AUX2
Each 100 ms, 0 = deactivated
0-250 0
119 Timer for switch off AUX3
Each 100 ms, 0 = deactivated
0-250 0
