Fahrzeug-/Funktionsdecoder ab Firmware-Version 1.11
42
Locomotive/Locomotive function decoder from firmware version 3.12
CV
Name and definition Range
Standard
52
Dimming LV/LR
0 = dark … 31 = full brightness
0-31 31
53
Dimming low beam light (see CV156)
0 = dark … 31 = full brightness
0-31 15
54
Dimming AUX1
0 = dark … 31 = full brightness
0-31 31
55
Dimming AUX2
0 = dark … 31 = full brightness
0-31 31
56
Motor control proportional
(not relevant to FH*)
Only if CV50 = 0, see: www
.doehler-haass.de/„Häufige Fragen“ (only in German)
0-7 3
57
Motor control integral
(as CV56)
0-3 3
58
Motor control measurement period
(as CV56)
0-3 1
59
Motor control impulse width
(as CV56)
0-7 3
60
Brake sections
1 or 2
0, 1 0
61 Shuntig gear speed
(as CV05) 0-127 63
62 Shunting gear deceleration
(as CV03) 0-255 1
63 Star
ting delay speed step 1
(see CV124)
Each 100 ms, 0 = deacitvated
0-250 0
64 Function mapping F2 (r)
(see supplement 1)
In case CV64 should have a different value than CV36,
you must set CV36 first and then CV64
0-255 8
