6.1.4 LEDs in the Ethernet connector
Two LEDs are integrated into each Ethernet connect. The right LED (yellow) will be illuminated
when a communication link is established to the DAU. The LED will flicker depending on the
traffic load. The left LED is not used. Please notice that the behavior of the LEDs is different from
other parts of the system for example the DAU.
6.1.5 Allocation of system labels for digital interfaces
Card number in VDR
configuration
Interface number in VDR
configuration and VDR
Explorer
Digital I/F module in Slot 3
1
DI00 – DI15
Digital I/F module in Slot 4
2
DI16 – DI31
Digital I/F module in Slot 5
3
DI32 – DI47
Digital I/F module in Slot 6
4
DI48 – DI63
6.1.6 MR address
Must be set to “0” for the first SIU and “1” for an additional second SIU.
