Danelec DM100-2014 - 2.2 Maximum number of supported interfaces

Operator's Manual for the DM100-2014 VDR
Copyright Danelec Marine A/S
2.2 Maximum number of supported interfaces
If needed, additional equipment may be used to make larger or non-standard configurations. The
maximum number of supported interfaces for a VDR is listed below:
Type of input
Maximum configuration
Ethernet interfaces*
7 on DAU
Serial inputs
40 (12 on DAU + 3 modules)
Analog inputs
32 (2 modules)
Digital inputs
128 (8 modules)
Audio inputs
14 (10 on DAU + 4 on RAI )
Video inputs**
4 (2 RVIs)
* For configuration of the VDR, acquiring network data and acquiring image data.
** The VDR records up to 8 image tracks. Four of these tracks may be used for recording images acquired by a Remote
Video Interface (optional equipment).
DBS11011-12 Page 8/27
