Operator's Manual for the DM100-2014 VDR
Copyright Danelec Marine A/S
8 Error codes
Error codes and messages will be displayed by the BCP.
8.1 Error codes
FATAL ERROR
The VDR has encountered an unrecoverable system error. Reboot
the system. If the error persists, the most probable cause is a
defective CPU board or defective system RAM
Unable to save
The VDR was unable to save the configuration. Please retry. This
error is only expected to occur during configuration (installation) of
Configuration failed
The VDR is unable to find any configuration at all. Replace the
compact flash in the DPU (a properly made boot flash contains a
default configuration from which the system can start). Restore a
backup of the configuration.
Running on battery
The system is running on battery. Both the main power and the
emergency power are absent. If there is a general power failure on
the vessel, ignore this message; otherwise check the power supply
in the DAU. Consult section 4 for details.
Microphones failed
The microphone test failed. Force a microphone test (this is a
feature on the BCP). This test will reveal which microphone is
causing the problem. Check that the “BMU active” checkbox is
unchecked for non-existing microphones. Check the cable for
microphone(s) reported as faulty. Test the inputs on the audio
interface module with a spare microphone. Replace microphones
which are reported faulty if no other error is discovered.
Power short circuit
One or more microphones are using too much power. The cabling
and microphones must be checked.
UTC timeout
The system is not receiving UTC from the GPS. Check that GPS is
on. Check the signal from the GPS (use serial monitor in VDR
explorer, WEB status or VGA status display). If no signal is
present check the cable otherwise check that the configuration has
Communication failed
The communication between the power supply circuit and the main
CPU in the DPU has been interrupted. If the error persists, the DPU
Missing (SI00-07)
The serial data interface module on the SAP board in the DPU
cannot be detected. If the error persists, the DPU is probably
Missing (VD01-02)
VIDEO module 1 cannot be detected. The most probable cause is
that the cable to the RVI from the DPU is disconnected or the RVI
is defective. In addition,
for an AC powered RVI: Power to the RVI
is switched off, the internal Ethernet cable in the RVI is
disconnected or the video interface module is defective.
Missing (MIC1-AUD5)
The audio data interface module on the SAP board in the DPU
cannot be detected. If the error persists, the DPU is probably
