Instructions
ECL Comfort 210 / 310, communication description
4.
RS-485 Modbus
The figure illustrates what a Modbus network might look like.
TCP/IP
, USB or
RS-232 to
RS-485 (Modbus)
ECL Comfort 310
as of version 1.10
M-Bus connection
Heat meter
Figure 4.1: Modbus network overview
Danfoss District Energy
VI.LG.V3.02
DEN-SMT/DK
5
4
6
