AlternativeconnectionforP3/M1,changeovervalve:
ApplicationA375.2/A375.3(burnersteps3–6):
Double-insulated(two-chamber)transformer
Terminal
Description
Max.load
48
PhaseforburnerB3
47
B3
BurnerON/OFF4(2)A/24Va.c.*
46
Nottobeused
45
PhaseforburnerB4
44
B4
BurnerON/OFF4(2)A/24Va.c.*
43
Nottobeused
42
PhaseforburnerB5
41
B5
BurnerON/OFF4(2)A/24Va.c.*
40
PhaseforburnerB6
39
B6
BurnerON/OFF4(2)A/24Va.c.*
*Relaycontacts:4Aforohmicload,2Aforinductiveload
68|©Danfoss|2017.09
VI.GU.L2.02
OperatingGuideECLComfort210/296/310,applicationA275/A375
