Instruction CF-RD Room Thermostat with Display
8 VI.UH.Q4.1C Produced by Danfoss Floor Heating Hydronics 03.2007
5. Mounting
Placing the Room Thermostat - g. 3
! Wherever possible, the room thermostat should be
installed at a place where the eect of sunlight, draught,
other heaters (eg. TV’s), etc. is avoided.
Mounting with screws - g. 2
Back plate
Screw hole for wall mounting
Screw and wall plug
6. Uninstallation
Activate Uninstall mode on Master Controller
- g. 1
• Use the Menu selection button
to choose the
Uninstall menu. Uninstall LED ashes
• Activate Uninstall mode by pressing OK
.
Uninstall LED goes ON
Deselect output on Master Controller
Select output to be removed by output selection
button
Remove ashing output with OK
