Danfoss 102E7 Installation & User's Instructions

8
1
2
3
5
6
L N
L
N
MAINS
SUPPLY
FUSED
3 AMP
ROOM
' S TAT
LINK
COM
CALL
N
BOILER &
PUMP
TERMINALS
102E5
TERMINALS
MID-POSITION VALVE
BLUE
GREY
SAT
WHITE
OR
BROWN
CALL
COM
CYL.
' S TAT
RED OR
ORANGE
Wiring
Typical Heating and Hot Water control system using
3-port mid-position valve
The above control system is available as the Danfoss
Randall 102E7 HEATSHARE pack, which also includes the
RMT room thermostat, AT cylinder thermostat, HS3 mid-
position valve and a WB12 wiring box.
102E7
TERMINALS

Danfoss 102E7 Specifications

General

Switching Voltage	230V AC
Power Supply	230V AC
Mounting	Wall Mounted
Voltage	230 V AC
Temperature Range	5°C to 30°C
