3. Mounting and wiring
This section describes how the controller:
• Is tted
• Is connected
We have decided to work on the basis of the example we went
through previously, i.e. the following modules:
• AK-PC 783 controller module
• AK-XM 204A output module
• AK-XM 208C analog input module + stepper output module
• AK-XM 102B digital input module
• AK-XM 103B analog input and output module
