Danfoss ADAP-KOOL Drive User Manual

13-11 Comparator Operator
Array [6]
Option: Function:
[0] * < Select < [0] for the result of the evaluation to be TRUE, when the variable selected in par.
13-10
Comparator Operand is smaller than the fixed value in par.13-12 Comparator Value . The result
will be FALSE, if the variable selected in par.13-10
Comparator Operand is greater than the fixed
value in par.13-12
Comparator Value .
[1] ≈ (equal) Select ≈ [1] for the result of the evaluation to be TRUE, when the variable selected in par.
13-10
Comparator Operand is approximately equal to the fixed value in par.13-12 Comparator Val-
ue
.
[2] > Select > [2] for the inverse logic of option < [0].
13-12 Comparator Value
Array [6]
Range: Function:
0 N/A* [-100000.000 - 100000.000 N/A] Enter the ‘trigger level’ for the variable that is monitored by this comparator. This is an array pa-
rameter containing comparator values 0 to 5.
3.10.4 13-2* Timers
This parameter group consists of timer parameters.
Use the result (TRUE or FALSE) from
timers directly to define an event (see par.13-51 SL Controller Event ), or as boolean input in a logic rule (see par.
13-40
Logic Rule Boolean 1 , par.13-42 Logic Rule Boolean 2 or par.13-44 Logic Rule Boolean 3 ). A timer is only FALSE when started by an action (i.e.
Start timer 1 [29]) until the timer value entered in this parameter is elapsed. Then it becomes TRUE again.
All parameters in this parameter group are array parameters with index 0 to 2. Select index 0 to program Timer 0, select index 1 to program Timer 1,
and so on.
13-20 SL Controller Timer
Array [8]
Range: Function:
0 N/A* [0 - 0 N/A] Enter the value to define the duration of the FALSE output from the programmed timer. A timer is
only FALSE if it is started by an action (i.e.
Start timer 1 [29]) and until the given timer value has
elapsed.
3.10.5 13-4* Logic Rules
Combine up to three boolean inputs (TRUE / FALSE inputs) from timers, comparators, digital inputs, status bits and events using the logical operators
AND, OR, and NOT. Select boolean inputs for the calculation in par.13-40
Logic Rule Boolean 1 , par.13-42 Logic Rule Boolean 2 and par.13-44 Logic Rule
Boolean 3
. Define the operators used to logically combine the selected inputs in par.13-41 Logic Rule Operator 1 and par.13-43 Logic Rule Operator 2 .
Priority of calculation
The results of par.13-40
Logic Rule Boolean 1 , par.13-41 Logic Rule Operator 1 and par.13-42 Logic Rule Boolean 2 are calculated first. The outcome
(TRUE / FALSE) of this calculation is combined with the settings of par.13-43
Logic Rule Operator 2 and par.13-44 Logic Rule Boolean 3 , yielding the final
result (TRUE / FALSE) of the logic rule.
13-40 Logic Rule Boolean 1
Array [6]
Option: Function:
[0] * False Enters the fixed value of FALSE in the logic rule.
[1] True Enters the fixed value TRUE in the logic rule.
[2] Running See parameter group 5-3* for further description.
3 Parameter Description ADAP-KOOL
®
Drive Programming Guide
108 MG.11.N1.02 - VLT
®
is a registered Danfoss trademark
3
