[121] gal/s
[122] gal/min
[123] gal/h
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lb/s
[131] lb/min
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[160] °F
[170] psi
[171] lb/in²
[172] in WG
[173] ft WG
[180] HP
21-11 Ext. 1 Minimum Reference
Range: Function:
0.000 Ex-
tPID1Unit*
[-999999.999 - par. 21-12 Ex-
tPID1Unit]
Select the minimum for the Closed Loop 1 Controller.
21-12 Ext. 1 Maximum Reference
Range: Function:
100.000 Ex-
tPID1Unit*
[par. 21-11 - 999999.999 Ex-
tPID1Unit]
Select the maximum for the Closed Loop 1 Controller.
The dynamics of the PID controller will depend on the value set in this parameter. Please see also
par.21-21
Ext. 1 Proportional Gain .
NB!
Always set the desired value for par.21-12
Ext. 1 Maximum Reference before setting the values for the PID controller in par. 20-9*.
