[2117] Ext. 1 Reference [Unit] The value of the reference for extended Closed Loop Controller 1
[2118] Ext. 1 Feedback [Unit] The value of the feedback signal for extended Closed Loop Controller 1
[2119] Ext. 1 Output [%] The value of the output from extended Closed Loop Controller 1
[2137] Ext. 2 Reference [Unit] The value of the reference for extended Closed Loop Controller 2
[2138] Ext. 2 Feedback [Unit] The value of the feedback signal for extended Closed Loop Controller 2
[2139] Ext. 2 Output [%] The value of the output from extended Closed Loop Controller 2
[2157] Ext. 3 Reference [Unit] The value of the reference for extended Closed Loop Controller 3
[2158] Ext. 3 Feedback [Unit] The value of the feedback signal for extended Closed Loop Controller 3
[2159] Ext. 3 Output [%] The value of the output from extended Closed Loop Controller 3
[2230] No-Flow Power The calculated No Flow Power for the actual operating speed
[2580] Pack Status
[2581] Compressor Status
[2587] Inverse Interlock
[2827] Discharge Temperature
[3110] Bypass Status Word
[3111] Bypass Running Hours
[11675] Wizard Init State
NB!
Please consult the
ADAP-KOOL Drive AKD 102 Programming Guide, MG.11.CX.YY for detailed information.
0-21 Display Line 1.2 Small
Option: Function:
Application Dependent Select a variable for display in line 1, middle position. The options are the same as listed for par.
0-20.
0-22 Display Line 1.3 Small
Option: Function:
Application Dependent Select a variable for display in line 1, right position. The options are the same as listed for par. 0-20.
0-23 Display Line 2 Large
Option: Function:
Application Dependent Select a variable for display in line 2. The options are the same as listed for par. 0-20.
0-24 Display Line 3 Large
Option: Function:
Application Dependent Select a variable for display in line 3. The options are the same as listed for par. 0-20.
3.2.5 0-3*LCP Custom Readout
It is possible to customize the display elements for various purposes: *Custom Readout. Value proportional to speed (Linear, squared or cubed depending
on unit selected in par.0-30
Custom Readout Unit ) *Display Text. Text string stored in a parameter.
Custom Readout
The calculated value to be displayed is based on settings in par.0-30
Custom Readout Unit , par.0-31 Custom Readout Min Value (linear only), par.
0-32
Custom Readout Max Value , par.4-13 Motor Speed High Limit [RPM] , par.4-14 Motor Speed High Limit [Hz] and actual speed.
3 Parameter Description ADAP-KOOL
®
Drive Programming Guide
38 MG.11.N1.02 - VLT
®
is a registered Danfoss trademark
3
