3-16 Reference 2 Source
Option: Function:
Select the reference input to be used for the second reference signal. par.3-15 Reference 1
Source
, par.3-16 Reference 2 Source and par.3-17 Reference 3 Source define up to three different
reference signals. The sum of these reference signals defines the actual reference.
This parameter cannot be adjusted while the motor is running.
[0] No function
[1] Analog input 53
[2] Analog input 54
[7] Pulse input 29
[8] Pulse input 33
[20] * Digital pot.meter
[21] Analog input X30/11
[22] Analog input X30/12
[23] Analog Input X42/1
[24] Analog Input X42/3
[25] Analog Input X42/5
[30] Ext. Closed Loop 1
[31] Ext. Closed Loop 2
[32] Ext. Closed Loop 3
3-17 Reference 3 Source
Option: Function:
Select the reference input to be used for the third reference signal. par.3-15 Reference 1 Source ,
par.3-16
Reference 2 Source and par.3-17 Reference 3 Source define up to three different reference
signals. The sum of these reference signals defines the actual reference.
This parameter cannot be adjusted while the motor is running.
[0] * No function
[1] Analog input 53
[2] Analog input 54
[7] Pulse input 29
[8] Pulse input 33
[20] Digital pot.meter
[21] Analog input X30/11
[22] Analog input X30/12
[23] Analog Input X42/1
[24] Analog Input X42/3
[25] Analog Input X42/5
[30] Ext. Closed Loop 1
[31] Ext. Closed Loop 2
[32] Ext. Closed Loop 3
3-19 Jog Speed [RPM]
Range: Function:
300. RPM* [0 - par. 4-13 RPM] Enter a value for the jog speed n
JOG
, which is a fixed output speed. The frequency converter runs
at this speed when the jog function is activated. The maximum limit is defined in par. .
See also par.3-80
Jog Ramp Time .
3 Parameter Description ADAP-KOOL
®
Drive Programming Guide
60 MG.11.N1.02 - VLT
®
is a registered Danfoss trademark
