Danfoss AK-LM 330 Design Guide

AK-LM 330 RS8FR302 © Danfoss 2015-08 13
Point
Signal Signal
type
S
Pt 1000 ohm/0°C
Saux
1-10
Pt 1000
P
AKS 32R
AKS 32
Paux1 -5
AKS 32R
-1 - xx bar
AKS 32
-1 - zz bar
U
Volt
input
1-5
0 - 5 V
0 - 10 V
On/O Active at:
Closed
/
Open
DO Active at:
On
/
O
Signal Module Point
Terminal
Signal type /
Active at
1
1 (AI 1) 1 - 2
2 (AI 2) 3 - 4
3 (AI 3) 5 - 6
4 (AI 4) 7 - 8
5 (AI 5) 9 - 10
6 (AI 6) 11 - 12
7 (AI 7) 13 - 14
8 (AI 8) 19 - 20
9 (AI 9) 21 - 22
10 (AI 10) 23 - 24
11 (AI 11) 25 - 26
12 (DO 1) 31 - 32
13 (DO 2) 33 - 34
14 (DO 3) 35 - 36
15 (DO 4) 37 - 38
16 (DO 5) 39 - 40- 41
17 (DO6) 42 - 43 - 44
18 (DO7) 45 - 46 - 47
19 (DO8) 48 - 49 - 50
Terminal 15: 12 V
Terminal 16: 5 V
Terminal 27: 12 V
Terminal 28: 5 V
Terminal
17, 18, 29, 30:
(Cable screen)
Solid state outputs
on 12 - 15
Relay or AKV coil
fx 230 V a.c.
Relay outputs on
16 - 19
Analog
inputs
on 1 - 11
Point 1 2 3 4 5 6 7 8 9 10 11
Type AI1 AI2 AI3 AI4 AI5 AI6 AI7 AI8 AI9 AI10 AI11
Point 12 13 14 15 16 17 18 19
Type DO1 DO2 DO3 DO4 DO5 DO6 DO7 DO8
24 and 25 not
used at monitor-
ing
3: Brown
2: Blue
1: Black
3: Brown
2: Black
1: Red
AKV
