Operation guide Installation, Operation and Maintenance APP 53-92 pumps
The APP 53-92 connections (inlet and outlet) can be adjusted in intervals of 45 degrees.
Please see typical installations with check valve VCM 92 mounted in the outlet port in the drawing
below. Non-standard congurations are available on request. For adjustment on site, please see
Installation, Operation and Maintenance Manual or contact Danfoss.
Non-standard conguration, turned 45 degrees left.Standard conguration
Non-standard conguration, turned 90 degrees left.
Non-standard conguration, turned 180 degrees .
