Operation guide Installation, Operation and Maintenance APP 53-92 pumps
180B4634 - APP 53-92 Screw kit 180B4635 - APP 53-92 Shaft seal kit 180B4636 - APP 53-92 Seal kit exc. shaft seal 180B4553 - APP 53 Piston kit 180B4554 - APP 65-92 Piston kit 180B4555 - APP 53-65 Retainer kit 180B4566 - APP 78 Retainer kit 180B4562 - APP 86-92 Retainer kit 180B4557 - APP 53-65 Valve plate kit 180B4558 - APP 78-92 Valve plate kit 180B4560 - APP 53 Swash plate kit 180B4601 - APP 65 Swash plate kit 180B4561 - APP 78-92 Swash plate kit 180B4556 - APP 53-92 Flushing valve kit 180B4559 - APP 53 -92 Cylinder barrel kit 180B4649 - APP 53-92 Port ange kit
2)
Pos. Qty. Description Material
0001 2 Complete Housing 1.4462/PEEK
0002 4 Pin ø6 x 10 A4
x
0003 6 Bleeding plug G1/4” 1.4410
x
0004 6 O-ring (ø11 x 2 mm) NBR
x
0005 51 Cyl.screw M8 x 30 A4-80 A4-80
x
0006 2 Screw M8 x 16 A4-80 A4-80
x
0009 4 O-ring (ø228x 4 mm) NBR
x x x x
0010 4 O-ring (ø9.2 x 2.6 mm) NBR
x x x
0011 1 End ange 1.4462
0014 1 Motor ange APP 53 - 92 1.4462
0144 4 Threaded pin M16 x 80 A4
0145 4 Hex lock nut M16 A4
0147 4 Washer ø17xø30x3 A4
0031 1 Swash plate APP 53 (non-drive end) 1.4410
x
0031 1 Swash plate APP 65 (non-drive end) 1.4410
x
0031 1 Swash plate APP 78-92 (non-drive end) 1.4410
x
0032 1 Swash plate APP 53 (drive end) 1.4410
x
0032 1 Swash plate APP 65 (drive end) 1.4410
x
0032 1 Swash plate APP 78-92 (drive end) 1.4410
x
0033 2 Distance washer
1)
PP
x
0034 4 Pin (ø10.5 x 20) 1.4410
x x x x
0064 2 Retainer ball DLC 1.4410/DLC
x x x
0065 2 Ass. Retainer plate 1.4410/PEEK
x x x
0061 2 Cyl.barrel with insert 1.4410/PEEK
x
0066 18 Piston 1.4410/PEEK
x
0066 18 Piston w. insert 1.4410/PEEK
x
0067 1 Key (14 x 9 x 70 A4
x
0068 1 Shaft APP H 1.4410
0069 1 Distance pipe APP 53-92 1.4462
0070 2 Pin (ø10.5 x 20) 1.4410
x
0072 1 Cone bushing DLC 1.4410/DLC
x
0073 1 Screw M16x75 DLC 1.4410/DLC
x
0081 9 Compression spring (ø1.9 x ø11 x 45.3) 1.4462
x x
0082 2 Assembly spring guide APP 53-65 1.4410/PP
x
0082 2 Assembly spring guide APP 78 1.4410/PP
x
0082 2 Assembly spring guide APP 86-92 1.4410/PP
x
0091 1 Port plate 1.4410/PEEK
x
0091 1 Port plate 17 1.4410/PEEK
x
0092 2 Int. Valve plate 1.4410
x
0092 2 Int. Valve plate 17 1.4410
x
0095 1 Port plate (shaft side) 1.4410/PEEK
x
0095 1 Port plate (shaft side) 17 1.4410/PEEK
x
0093 18 Back-up ring PTFE/Carbon
x x x
0094 18 O-ring (ø30.2 x 3 mm) NBR
x x x
2. Parts list
APP 53-92 - serial no. 07
or higher
