Operation guide Installation, Operation and Maintenance APP 53-92 pumps
Parts list (continued)
APP 53-92 - serial no. 07 or
higher
7
180B4634 - APP 53-92 Screw kit 180B4635 - APP 53-92 Shaft seal kitseal kit 180B4636 - APP 53-92 Seal kit exc. shaft seal 180B4553 - APP 53 Piston kit 180B4554 - APP 65-92 Piston kit 180B4555 - APP 53-65 Retainer kit 180B4566 - APP 78 Retainer kit 180B4562 - APP 86-92 Retainer kit 180B4557 - APP 53-65 Valve plate kit 180B4558 - APP 78-92 Valve plate kit 180B4560 - APP 53 Swash plate kit 180B4601 - APP 65 Swash plate kit 180B4561 - APP 78-92 Swash plate kit 180B4556 - APP 53-92 Flushing valve kit 180B4559 - APP 53-92 Cylinder barrel kit 180B4649 - APP 53-92 Port ange kit
2)
Pos. Qty. Description Material
0121 1 Center ange APP H 1.4462
x
0122 1 O-ring (ø80.0 x 2 mm) NBR
x
0124 1 Shaft seal NBR
x
0125 1 Cover for shaft seal 1.4462
0126 4 Pin (ø10.5 x 20) 1.4410
x x x
0127 4 Screw M6 x 12 A4-80 A4-80
x
0128 50 Screw M8 x 20 A4-80 A4-80
x
0131 1 3” Cover for Inlet port PP
0132 2 O-ring (ø79 x 3.5) NBR
x
0133 4 Screw M8 x 16 A4-80 A4-80
0134 1 3” Cover for Outlet port PP
0135 4 Screw M10 x 16 A4-80 A4-80
0140 1 Lifting eye M12 (DIN 580E) AISI 316
0142 1 Washer for shaft seal 1.4462
x
0151 1 O-ring (ø35 x 3) NBR
x x
0152 1 Valve cone 1.4410
x
0153 1 Compression spring 1.4462
x
0154 1 Plug/guide 1.4410
x
0155 1 O-ring (ø47.2 x 3.5) NBR
x x
1 Instruction
x x x x x x x x x x x x x x x x
1)
Not mounted in APP 53
2)
Only compatible with pump series 08 or higher
