Operation guide Installation, Operation and Maintenance APP 53-92 pumps
BoWex-ELASTIC
®
Operating/Assembly instructions
Type HEW, HEW Compact and HEW-ZS
KTR-N
Sheet:
Edition:
40114 EN
1
of 22
7
Please observe protection
note ISO 16016.
Drawn:
2017-04-24 Shg/Hk
Replacing:
KTR-N dated 2013-06-10
Verified:
2017-04-24 Shg
Replaced by:
BoWex-ELASTIC
®
highly flexible flange coupling type
HEW1, HEW2 and their combinations
according to directive 2014/34/EU
for finish bored, pilot bored and unbored couplings
Type HEW1
Type HEW2
BoWex-ELASTIC
®
highly flexible flange coupling types
HEW Compact and HEW-ZS and their combinations
for finish bored, pilot bored and unbored couplings
Type HEW Compact
Type HEW-ZS
