Danfoss APP series

180R9346 | AQ240486503020en-001702 | 67© Danfoss | 2023.03
Operation guide Installation, Operation and Maintenance APP 53-92 pumps
BoWex-ELASTIC
®
Operating/Assembly instructions
Type HEW, HEW Compact and HEW-ZS
KTR-N
Sheet:
Edition:
40114 EN
7
of 22
7
Please observe protection
note ISO 16016.
Drawn:
2017-04-24 Shg/Hk
Replacing:
KTR-N dated 2013-06-10
Verified:
2017-04-24 Shg
Replaced by:
Warning of potentially explosive
atmospheres
This symbol indicates notes which may contribute to pre-
venting bodily injuries or serious bodily injuries that may
result in death caused by explosion.
STOP
Warning of personal injury
This symbol indicates notes which may contribute to pre-
venting bodily injuries or serious bodily injuries that may
result in death.
!
Warning of product damages
This symbol indicates notes which may contribute to pre-
venting material or machine damage.

General advice
This symbol indicates notes which may contribute to pre-
venting adverse results or conditions.
Warning of hot surfaces
This symbol indicates notes which may contribute to pre-
venting burns with hot surfaces resulting in light to seri-
ous bodily injuries.
STOP
With assembly, operation and maintenance of the coupling it has to be made sure that the
entire drive train is secured against accidental switch-on. You may be seriously hurt by ro-
tating parts. Please make absolutely sure to read through and observe the following safety
indications.
 All operations on and with the coupling have to be performed taking into account "safety first".
 Please make sure to switch off the power pack before you perform your work on the coupling.
 Secure the power pack against accidental switch-on, e. g. by providing warning signs at the place of switch-on
or removing the fuse for current supply.
 Do not reach into the operating area of the coupling as long as it is in operation.
 Please secure the coupling against accidental contact. Please provide for the necessary protection devices
and covers.
You may only assemble, operate and maintain the coupling if you
 have carefully read through the operating/assembly instructions and understood them
 had technical training
 are authorized by your company
The coupling may only be used in accordance with the technical data (see table 1 to 4 in chapter 1). Unauthorized
modifications on the coupling design are not admissible. We will not assume liability for any damage that may
arise. In the interest of further development we reserve the right for technical modifications.
The BoWex-ELASTIC
®
type HEW, HEW Compact and HEW-ZS described in here corresponds to the technical
status at the time of printing of these operating/assembly instructions.
2 Advice
2.3 Safety and advice symbols
2.4 General hazard warnings
2.5 Intended use
